- Page 1 HEX70CS-KIT User Manual RevA3 HEX70CS-KIT User Manual...
- Page 2 HEX70CS-KIT USER MANUAL Contents Thank you for purchasing Introduction this product. For optimum performance and safety, Features please read these instructions carefully before connecting, operating or Panel Descriptions adjusting this product. Please keep this manual for future reference. Terminating HDBaseT™ CAT Cables Understanding HDBaseT™...
- Page 3 HEX70CS-KIT USER MANUAL Introduction Our HEX70CS-KIT HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) HDCP 2.2 HDBaseT™ extender set offers market leading features and outstanding value utilising CSC technology. The product extends HDMI, Bi-directional IR & RS-232 and Bi-directional PoC (PoE) up to lengths of 70m (4K 40m). The Transmitter includes a HDMI loop-out for integrating local displays or cascading to multiple devices.
- Page 4 HEX70CS-KIT USER MANUAL Panel Description HEX70CS-RX Mode dip-switch - To switch RS-232 serial port Coaxial digital output - de-embedded from HDMI input between pass-through and firmware update mode Analogue audio left / right output (3.5mm stereo jack RS-232 / serial connector de-embedded from HDMI input.
- Page 5 1 2 3 4 5 6 7 8 T568B Understanding the Transmitter / Receiver Status Lights The Blustream HEX70CS-KIT extender solutions include status LED indicators on both the Transmitter and Receiver products to show all connections are active and to help diagnose possible problems. Receiver: •...
- Page 6 HEX70CS-KIT USER MANUAL EDID Control EDID (Extended Display Identification Data) is a data structure that is used between a display and a source. This data is used by the source to find out what audio and video resolutions are supported by the display. By pre-determining the video resolution and audio format of the source and display device you can reduce the time needed for EDID hand shaking thus making switching quicker and more reliable.
- Page 7 HEX70CS-KIT USER MANUAL Infrared (IR) Distribution The Blustream range of HDBaseT™ products include multiple options for control and routing of IR. IMPORTANT: Blustream Infrared products are all 5v and NOT compatible with alternative manufacturers Infrared solutions. When using third party 12v IR control solutions please use the optional Blustream IRCAB cable for IR conversion.
- Page 8 HEX70CS-KIT USER MANUAL...
- Page 9 HEX70CS-KIT USER MANUAL Specifications HEX70CS-TX HEX70CS-RX • Video input: 1 x HDMI Type A, female • Video input: 1 x HDBaseT™ RJ45 connector • Video output: 1 x HDBaseT™ RJ45 connector • Video output: 1 x HDMI Type A, female •...
