Hinged Bathscreen
Instruction Manual
KLBV / TLBV
Be aware toughened glass can shatter if not handled correctly. It should not
be subjected to any sharp impact and it is essential to protect the glass by
resting it on a soft protective surface during installation such as cardboard
or carpeting. It is recommended to wear PPE at all times during installation.
PRE-INSTALLATION CHECKS
1.
Check you have the correct product. Please look at the labels on the side of the product packaging.
2.
Check all the product components are in the box and the fixing kits.
3.
Unpack your product and handle it with care.
4.
Please check the product for defects or damage, once the installation has commenced we cannot accept responsibility for any defects or
damage.
5.
Please take time to read these instructions prior to installing your product.
6.
Before you commence any drilling check there are no hidden electrical cables and/or water pipes.
7.
No attempt should be made to re-work the toughened safety glass.
8.
The installation of the product should be performed by two persons.
9.
It is strongly recommended that the walls the product is going to be installed on are vertical.
10. It is strongly recommended the product is fitted on a tiled surface or similar waterproof surface.
11. It is strongly recommended the walls are tiled and grouted before the product is installed.
12. If the walls and/or the tray are not level you will not achieve maximum adjustment of the product.
13. Pictures used are for illustration purposes only, product designs may alter slightly as a result of continuing product development.
14. We do not stipulate where the European Standard Kite Mark should be positioned on the glass when being factory assembled.
15. Please note that some natural misting may occur when you remove this product from its packaging, due to the addition of the glass protection
pre-coating. If this does occur this can easily be removed with a soft, dry cloth.
Equipment Check List: Not Supplied
Description
Electric / Battery Drill
Pozi Screwdriver
Sealant Gun / Sealant
Spirit Level (Large)
6mm Masonry Drill Bit
Tape Measure
Pencil
Torque Wrench
Stanley Knife / Snips
Fixing Kit Components
Description
Door Setting Blocks
38mm Long Csk Head Screws
Wall Plugs
Hinge Spacer Gaskets
Branding Clip
Ref: KLBV/TLBV - Rev 2 May 2022
IMPORTANT INFORMATION
Quantity
4
5
5
4
1
Component Check List: Supplied
Description
Hinged Panel Assembly
Moving Panel Glass
Bottom Rail
Door Bottom Rail
Glass-to-Glass Hinges
Profile to Damn Joint
End Cap (LH & RH)
Bottom Deflector Seal
Bracing Assembly (LH & RH)
Vertical Flipper Seal
Wall Brackets
Hinge Backplate & Flipper Gasket
Wall Profile
Blanking End (LH & RH)
Wall Profile Top Cap
CONSUMER GUARANTEE
Please make sure the purchaser/end user
completes and returns the guarantee card
which is enclosed with this product. Failure
to validate the Guarantee will mean only the 1
Year Statutory Guarantee will apply.
Quantity
1
1
1
1
2
1
1 Each
1
1 Each
1
2
2
1
1 Each
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ROMAN KLBV
Summary of Contents for ROMAN KLBV
- Page 1 Please make sure the purchaser/end user completes and returns the guarantee card which is enclosed with this product. Failure to validate the Guarantee will mean only the 1 Year Statutory Guarantee will apply. Ref: KLBV/TLBV - Rev 2 May 2022...
-
Page 2: Step 1 - Pre-Installation Checks
Step 1 - Pre-installation Checks ④ ③ ① ② 1. Check that the bath is level on all sides. • The bubble should be in the centre of the 2 lines on the spirit level. 2. Stand in the bath and check there is no adverse movement. 3. - Page 3 Step 2 - Wall Profile Positioning NOTE: Placing some masking tape on the tiled wall in the position where the wall profile is to go will not only help with marking out, but will also help protect the tiles when drilling. ②...
- Page 4 Step 3 - Panel Wall Bracket Positions Note: We recommend 2 people carry out the procedures below. ② Gasket ③ ⑤ Mark Through Holes Wall Inside Profile View ② ⑤ Wall Profile Outside View 1. Place the panel assembly into the panel bottom strip and dam to profile joint, then carefully place into the wall profile.
- Page 5 Step 4 - Fitting the Hinged Panel Note: We recommend 2 people carry out the procedures below. ① Dam to Profile Joint Panel Rail ② Door Bottom Rail ② Bottom Rail ③ Gasket Outside View 1. Carefully place the panel assembly along with the bottom rail and dam to profile joint into the wall profile.
- Page 6 Step 5 - Fitting the Moving Panel Note: We recommend 2 people carry out the procedures below. ① ③ Long ④ Keep Fully Vertical when Fitting Short Bottom ② ④ Flipper Gasket Outside View Hinged ④ ① Panel side Flipper Gasket Fixed Panel side ①...
- Page 7 Step 6 - Fitting the Seals ③ ① Cut Any Excess ① Rebate Rebate ② Cut Any Excess ④ ② ③ Flipper Rebate 1. At the bottom of panel assembly, place a bead of silicon between the plass and the bottom rails. Fit the blanking end and carefully remove any excess silicon.
- Page 8 Step 7 - Bracing and Sealing ① Wall ② Bracket ③ ⑫ Branding Badge ⑧ ⑨ ⑩ ⑩ ⑪ Silicon Silicon 1. Put the bracing on the top of the fixed panel glass and up to the tiled walls, use a spirit level to keep it the bracing horizontal.
-
Page 9: Spare Parts
Spare Parts If you need to replace any damaged parts please see illustration below for parts list then call Customer Relations on 01325 328033 Part No. Description Part No. Description Hinged Panel Assembly LH Blanking End Moving Panel Glass RH Blanking End Glass-to-Glass Hinges Hinge Backplate &... -
Page 10: Troubleshooting Guide
TROUBLE SHOOTING GUIDE Problem Solution 1. Check that the bottom rail has been sealed correctly on the outside only. Leaking 2. Ensure the bath is sealed along the tiled walls prior to installation. 3. If the inside joint between the screen and the bath top is sealed, this will cause leakage - sealant must be removed.
Need help?
Do you have a question about the KLBV and is the answer not in the manual?
Questions and answers
