Neo Angle
Instruction Manual
DXP
Be aware toughened glass can shatter if not handled correctly. It should not
be subjected to any sharp impact and it is essential to protect the glass by
resting it on a soft protective surface during installation such as cardboard
or carpeting. It is recommended to wear PPE at all times during installation.
PRE-INSTALLATION CHECKS
1.
Check you have the correct product. Please look at the labels on the side of the product packaging.
2.
Check all the product components are in the box and the fixing kits.
3.
Unpack your product and handle it with care.
4.
Please check the product for defects or damage, once the installation has commenced we cannot accept responsibility for any defects or damage.
5.
Please take time to read these instructions prior to installing your product.
6.
Before you commence any drilling check there are no hidden electrical cables and/or water pipes.
7.
No attempt should be made to re-work the toughened safety glass.
8.
The installation of the product should be performed by two persons.
9.
It is strongly recommended that the walls the product is going to be installed on are vertical.
10. It is strongly recommended the product is fitted on a tiled surface or similar waterproof surface.
11. It is strongly recommended the walls are tiled and grouted before the product is installed.
12. If the walls and/or the tray are not level you will not achieve maximum adjustment of the product.
13. Pictures used are for illustration purposes only, product designs may alter slightly as a result of continuing product development.
14. We do not stipulate where the European Standard Kite Mark should be positioned on the glass when being factory assembled.
15. Please note that some natural misting may occur when you remove this product from its packaging, due to the addition of the glass protection pre-
coating. If this does occur this can easily be removed with a soft, dry cloth.
Component Check List: Supplied
Description
Wall Profiles / Wall Profile Top Caps
Wall Profile Covers
Hinge Panel Assembly / Plain Panel Assembly
Door Glass
Braciing Assembly / Handle Assembly
Hinge Assemblies
Door Joints (Left and Right Hand)
Bottom Rails
Door Rail (Sloped)
Vertical Panel and Vertical Door Seal
Door Bottom Seal
Equipment Check List: Not Supplied
Description
Electric / Battery Drill
Pozi Screwdriver
Sealant Gun / Sealant
Torque Wrench
Spirit Level (Large)
7mm Masonry Drill Bit
Tape Measure
Pencil
IMPORTANT INFORMATION
Quantity
Description
2 of each
2.5mm Drill Bit
4
9mm long Cap Head Screws
9mm long Csk Head Screws
1 of each
40mm long Cap Head Screws
1
Wall Plugs (Brown)
1 of each
Branding Clip
2
Door Setting Blocks
1 of each
2.5mm Allen Key
3
3mm Allen Key
1
4mm Allen Key
1 of each
Bottom Packers
1
Top Packers
Fixing Kit Components
CONSUMER GUARANTEE
Please make sure the purchaser/end user
completes and returns the guarantee card
which is enclosed with this product. Failure
to validate the Guarantee will mean only the 1
Year Statutory Guarantee will apply.
Quantity
Door
Panels
-
1
-
20
-
4
-
16
-
16
-
1
4
-
1
-
1
-
1
-
8
-
4
-
Ref: DXP REV2 - SEPT 2019
