- Page 1 USER MANUAL...
-
Page 2: Table Of Contents
CONTENT CONTENT ........................01 PRECAUTIONS ON SAFE OPERATION ..............02 CHAPTER 1 ABOUT THE INSTRUMENT ............03 I. APPLICATION .....................03 II. TECHNICAL SPECIFICATION ................03 III. EXTERNAL FEATURES & PARTS ..............06 IV. FUNCTIONS OF PARTS ...................07 CHAPTER 2 INSTALLATION OF INSTRUMENT ..........11 I. PLACEMENT OF INSTRUMENT ...............11 II. -
Page 3: Precautions On Safe Operation
II. TECHNICAL SPECIFICATION PRECAUTIONS ON SAFE OPERATION CHAPTER 1 ABOUT THE INSTRUMENT I. APPLICATION PRECAUTION: 1) This series of product is designed for sterilizing,drying heat and high pressure * For your safety and to operate the instrument properly, please read this Operation Instruction carefully before using and operate following the requirements in this manual. - Page 4 Model GR60DF GR85DF GR100DF GR110DF Capacity 100L 110L Dimension(LxWxM,mm) 660x644x980 660x644x980 660x644x1180 660x644x1180 Model GR60DA GR85DA GR100DA GR110DA Chamber ф400×505 ф400×700 ф400×800 ф400×895 Capacity 100L 110L Dimension(Dia*H, mm) Dimension(LxWxM,mm) 660x644x980 660x644x980 660x644x1180 660x644x1180 Net Weight 101kg 113kg 120kg 125kg Chamber ф400×505 ф400×700 ф400×800...
- Page 5 Water level tube is not for DA series DF series only have water feeding filter Cooling fan is Optional for DA Series DR series have both water feeding filter and drain filter Cover of water tank of DA series can not be opened...
- Page 6 26. Drying/Warming status indicator: The light blinks in course of drying or warming 2.WATER: Water level indicator (only for DR Series and DF Series). Under standby condition, 27. WARM: *WARM* is light, and drying/warming status indicator is blinking to indicate the indicator on means that there is sufficient water in sterilization chamber for sterilization, and that the instrument is in warming stage.
-
Page 7: Chapter 2 Installation Of Instrument
2*Cooling Lock Function CHAPTER 2 INSTALLATION OF INSTRUMENT In general condition, the cooling of chamber will be faster than that of sterilized articles, and in other words, the actual temp of load may be higher than the value on meter (especially for liquid). I. -
Page 8: Chapter 3 Operation Instruction
* When the instrument is in standby status, if there is no operation within 30min, CHAPTER 3 OPERATION INSTRUCTION the instrument may enter the power down mode automatically, all the indicators except the LOCKED indicator will be off. Press any key to resume. I. - Page 9 2) DF Series / DR Series chamber, so that it will not be put on the heater directly.The load thermometer * Check if WATER indicator on display panel is on, when WATER indicator is off, should be placed on water level plate and kept in sound.
- Page 10 U02, U03, U04 , U05 and U06 before delivery. * Press *DATA* button, the digital display A and B will display the detailed * DR Series are designed with six basic working modes saved as U01, U02, parameters once by three screens: U03, U04 , U05 and U06 before delivery.
- Page 11 Screen 1 Screen 2 * U03 default parameters and the parameters scope of its newly generated LOCKED WATER LIQUID SOLID AGAR CLOCK LOCKED WATER LIQUID SOLID AGAR CLOCK program 135.0 Default Parameters Range Name Parameter of New Program Sterilizing Temperature 121℃...
- Page 12 * Note: Default Parameters Range DELY Time: It means that it will prolong the airpurgeing time to obtain sufficient Name Parameter of New Program saturated steam, but overlong DELY time may lead to water shortage in subsequent sterilization stage. Sterilizing Temperature 121℃...
-
Page 13: Starting Sterilization
* Power must be switched off when the work has been finished or the instrument will not be used for a long period of time. * DF Series / DR Series: When sterilization is completed of a day, it is recommended to drain out all water in sterilization chamber and water tank. -
Page 14: Creating, Modifying, Deleting The Program
II. CREATING, MODIFYING, DELETING THE PROGRAM * Note: The parameters of programs can only be modified under standby status, and the set parameters cannot be changed during sterilizing. 1. CREATING AND MODIFYING THE PROGRAM Press the *NEXT* button at each time, the parameters of basic programs and the newly generated program from which will be modified by the following sequence: Press the *UP* or *DOWN* button to find the program of the desired mode U01~U06, and then press *SET/ENT* to enter the parameters modification... -
Page 15: Deleting The Program
III. CLOCK CHECKING AND CALIBRATION 2. DELETING THE PROGRAM * Under standby status, press *FUNC* and *NEXT* buttons together to enter the clock checking and calibration mode F05, with the digital display A and * Select the program to be deleted, and press and hold the *FUNC* & B showing the currently parameters automatically by sequence: *STOP* button at the same time to delete the current program. -
Page 16: Iv.setting Auto Startup Timer
6) Press *NEXT* button again, the time and minute indicators on the digital 5) Press *NEXT* button again, the digital display B (minute) blinks to display B blink to indicate that it is ready for modification. Press *UP* or indicate that it is ready for modification. Press *UP* or *DOWN* to *DOWN* to increase or decrease the display value by 1 minute at one increase or decrease the display value by 1 minute at one press. -
Page 17: Chapter 4 Maintenance,Care & Management
* Water feeding filter and drain filter are available for DR series, drain filter is * Note: If the sterilizer will not be used for a long period of time or need to available for DF series transport, the water in the water tank must be emptied. -
Page 18: Others
Slightly press the surface of sealing ring with hand to keep material, the filter core should be replaced. it smooth. The cover of chamber will be hard to be closed for unsmooth surface * Air filter is available for DR series of sealing ring. 2) Maintenance of sealing ring * Operate the instrument in a conventional way and observe the air-tightness * Check if the sealing ring is broken and replace it immediately if broken. -
Page 19: Iii.setting Of Administrator
CHAPTER 5 TROUBLESHOOTING III. SETTING OF ADMINISTRATOR * The automatic control system of the sterilizer monitors the real time * Under standby condition, press and hold FUNC and DATA buttons, then operation of the instrument. Whenever any failure occurs, the system may send out alarm and display the error code, then, please press the STOP button and screen A will show *0000* Among these, the first *0* flashing means it is. -
Page 20: Chapter 6 Diagram Of Pipeline & Interface
CHAPTER 6 DIAGRAM OF PIPELINE & INTERFACE Failure of heating system or Contact the local dealer temperature control system Water level of sterilization chamber Add water to chamber I.PIPELINE FOR GR60DA/GR85DA/GR100DA/GR110DA is too low Load temperature sensor comes Plug the temperature sensor in off the circuit board place Load temperature sensor is not... - Page 21 CHAPTER 7 WIRING DIDAGRAM IV. INTERFACE DIAGRAM Interface of Temperature I. WIRING DIAGRAM FOR GR60DA/GR85DA/GR100DA/GR110DA Test G1A Interface of Temperature Test Transformer Rc3/4 Filter Leakage protection switch Power transformer Interface of Load Temperature Sensor Rc3/4 Power AC220V Terminal base Power switch Shell Ground the Interface of Pressure Test...
- Page 22 II. WIRING DIAGRAM FOR GR60DF/GR85DF/GR100DF/GR110DF III.WIRING DIAGRAM FOR GR60DR/GR85DR/GR100DR/GR110DR Transformer Filter Leakage protection switch Transformer Filter Leakage protection switch Power Power transformer transformer Power AC220V Terminal base Power switch Power AC220V Terminal base Power switch Shell Ground the Shell Ground the instrument instrument properly thermo switch...
