F 22SM
F 27SM
F 10SM
UPRIGHT FREEZER
Instruction for Use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F 22SM and is the answer not in the manual?

Questions and answers

Related Manuals for SNAIGE F 22SM

Summary of Contents for SNAIGE F 22SM

  • Page 1 F 22SM F 27SM F 10SM UPRIGHT FREEZER Instruction for Use...

  • Page 2: General Information

    DEAR CUSTOMER! Some provisions in this user manual are unified for refrigerating products of different types (for a refrigerator, refrigerator-freezer or freezer). CAREFULLY READ THE INSTRUCTION MANUAL. The Manufacturer shall not be held liable for damage arising from the failure to observe the instructions contained in this manual.
  • Page 3 Immediately ventilate the room: air the room in which the appliance is placed for a • few minutes (the size of the room for a product containing isobuthane / R600a must be at least 4 m ) to avoid damage to the cooling system. C-Pentane is used as blowing agent in the insulation foam and it is a flammable gas.
  • Page 4 bent, straightened or wound. If the capillary tube is damaged by the user the guarantee will be void. Do not use adapters, multiple sockets and two-wire extension leads. If it is – necessary to use the extension lead, it must be equipped with a protection ring and a single socket and must have a VDE/GS safety certificate.

  • Page 5: Installation And Operating Conditions

    (see fig.).  The appliance must stand on a level surface • and must not touch the wall. If necessary, F 10SM F 22SM, F 27SM regulate the height of the appliance by adjusting...

  • Page 6: Preparing For Operation

    When placing F 22SM and F 27SM take two supports 1 from the bag and insert them • into the guides 2 at the top back part of the appliance....
  • Page 7 If the unit has been tilted more than 30° during transport: wait at least 4 hours before connecting the appliance to the power supply. If this is not done, the appliance compressor may fail. When first starting-up or after a period out of use, before putting the products in the •...

  • Page 8: Temperature Regulation

    The temperature indication in digits is shown beside the thermostat knob. The number “0, 2, 3, 4, 5, 6, 7” do not mean a specific temperatures. In the freezers F 22SM and F 27SM the temperature is regulated on the scale of seven digits: 0 = Compressor is switched off.
  • Page 9 4 = lowest temperature (maximum refrigeration) The numbers do not mean a specific temperatures. The temperature in the freezer compartment can vary due to the ambient temperature, the amount of food, and the frequent opening of the freezer door. IF THE ROOM IS COOL, THE APPLIANCE COOLS LESS. THE TEMPERATURE IN THE APPLIANCE MAY THEREFORE RISE.
  • Page 10 F 22SM, F 27SM (see fig. 4): Pull out the melt water gutter, turn • it 180° and hook it up. After thawing, place the container with the water gutter.

  • Page 11: Changing The Opening Direction Of The Doors

    Do the actions below in the order they are listed: • F 22SM, F 27SM: W A RN I N G ! Turn off the freezer and pull the plug out of the electricity supply outlet. 1. Remove covers c from the inside of the housing and door and the upper bracket 6 together with the nut and washers and the gasket under the bracket.
  • Page 12 6. Remove the screw caps a and the blinds b. Unscrew the 9 fixing screws of the handle and screw the handle on the opposite side of the door. Press the blinds into the remaining holes in the door and place the covers on the screws. 7.
  • Page 13 OPERATION PROBLEMS AND THEIR SOLUTIONS The appliance is plugged in to the mains but it does not work and the • electricity supply voltage indicator is not illuminated. Check that your house electricity supply installations are in order. Check that the plug is correctly inserted into the electricity supply socket.

  • Page 14: Environmental Protection Information

    ENVIRONMENTAL PROTECTION INFORMATION Important Note: This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.

This manual is also suitable for:

F 27smF 10sm
