- Page 1 PJ1000M-C User Manual Volume 1 Manufactured by Italy...
- Page 2 Limitations of use can apply in respect of operating freuency, transmitter power and/or channel spacing. Declaration of Conformity Hereby, R.V.R. Elettronica SpA, declares that this FM transmitter is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
-
Page 3: Table Of Contents
PJ1000M-C Table of Contents 1. Preliminary instructions 2. Warranty 3. First Aid 3.1 Treatment of electrical shocks 3.2 Treatment of electrical Burns 4. General Description 5. Installation and Use 5.1 Preparation 5.2 Use 5.3 Encoder 6. Software 6.1 Main Menu 6.2 RF Power in menu... - Page 4 PJ1000M-C This page was intentionally left blank Rev. 1.1 - 10/11/03 User Manual...
-
Page 5: Preliminary Instructions
This is a "CLASS A" equipment. In a residential place this equipment can cause hash. In this case can be requested to user to take the necessary measures. R.V.R. Elettronica SpA reserves the right to modify the design and/or the technical specifications of the product and this manual without notice. - Page 6 PJ1000M-C This page was intentionally left blank 2 / 24 Rev. 1.1 - 10/11/03 User Manual...
-
Page 7: Warranty
2 If your dealer cannot help you, contact R.V.R. Elettronica and explain the problem. If it is decided to return the unit to the factory, R.V.R. Elettronica will mail you a regular authorization with all the necessary instructions to send back the goods. - Page 8 Replacement and warranty parts may be ordered from the following address. Be sure to include the equipment model and serial number as well as part description and part number. R.V.R. Elettronica SpA Via del Fonditore, 2/2c 40138 BOLOGNA ITALY Tel.
-
Page 9: First Aid
PJ1000M-C 3. First Aid Il personale impegnato nell’installazione, nell’uso e nella manutenzione dell’apparecchiatura deve avere familiarità con la teoria e le pratiche di primo soccorso. 3.1 Treatment of electrical shocks 3.1.1 If the victim is not responsive Follow the A-B-C's of basic life support •... -
Page 10: Treatment Of Electrical Burns
PJ1000M-C 3.1.2 If the victim is responsive • Keep them warm • Keep them as quiet as possible • Loosen their clothing (a reclining position is recommended) • Call for medical help as soon as possible 3.2 Treatment of electrical Burns 3.2.1 Extensive burned and broken skin... -
Page 11: General Description
PJ1000M-C 4. General Description RVR Elettronica’s PJ1000M-C is an extremely compact (just 3 U) 19” rack-mountable broadband MOSFET RF power amplifier for FM audio broadcasting. It works without adjustment in the whole 87.5-108MHZ FM band, its overall efficiency is about 70 %, so that its power consumption is just about 1450 W at its nominal 1000 W RF output. -
Page 12: Installation And Use
265 V. The amplifier will perform automatic restart as soon as the problem in the mains supply will be removed. The PJ1000M-C includes a mains switch on the rear panel, completely breaking the mains supply. Verify that it is in the “Off” position. -
Page 13: Use
Increase the exciter’s output power until the LED “AGC LOW” goes off and “AGC OK” is lit. This is the optimum driving condition. The PJ1000M-C is normally delivered with the output power set low (approx 50 W). The power setting can be performed directly or indirectly, depending on the exciter being connected ad active or not. -
Page 14: Encoder
Remote mode is prioritaire. Before resetting the alarms, it’s necessary to pass in “local” mode! 5.3 Encoder The PJ1000M-C’s control system is based on a LCD and a knob (“encoder”). With this system the user can check and modify all the configurations, like powerlevel, power output activation, local or remote mode. -
Page 15: Software
PJ1000M-C 6. Software The amplifier is fitted with a two lines LCD showing a set of menus. In some cases, the menu reports the indication “Push to Program”: in this case, pushing the encoder will enable the modification of the parameter, if necessary. -
Page 16: Power Amplifier Menu
PJ1000M-C 6.3 Power Amplifier menu This screenful reports the power supply status of the RF amplifier: • Voltage (VPA) • Current (IPWS) VPA is the voltage at the input of the RF modules. Note that the output power level of the amplifier is controlled varying this voltage. -
Page 17: Alarms Menu
PJ1000M-C 6.6 Alarms menu This menu gives to the user all the information related to the embedded protection system of the amplifier.. It comprises a number of sub-menus, each containing the name of the variable checked by the protection system and the number of the protection interventions, due to this variable, performed by the system. -
Page 18: Alarms Sub-Menus
PJ1000M-C 6.7 Alarms sub-menus Maximum permitted reflected power Maximum permitted forward power Maximum input power Maximum permitted temperature at the RF amplifier section Maximum permitted temperature at the power supply section Maximum permitted current for the right couple of MOSFET modules... -
Page 19: Mode Selection Menu
Rotating the encoder, put the cursor on the desired choice. The external interlock permits to an external device, for example a telemetry system, to inhibit the power output of the PJ1000M-C, using the connectors “EXT SET” and “INTRLK IN” on the back of the machine. -
Page 20: Power Menu
In REMOTE mode, the machine will not be controlled by the encoder anymore. In particular, it’s not possible to switch the power ON and OFF, nor to adjust the output power. Never put the PJ1000M-C in Remote mode if you don’t know exaxtly what you do. -
Page 21: Software Release Menu
PJ1000M-C 6.10 Software release menu This screenful gives the release numbers of the different parts of the firmware controlling the amplifier, that is: • Overall management • Protection section • Telecontrol section These data will help the maintenance personnel to correctly identify your piece of equipment. - Page 22 PJ1000M-C This page was intentionally left blank 18 / 24 Rev. 1.1 - 10/11/03 User Manual...
-
Page 23: External Description
PJ1000M-C 7. External description This chapter enumerates the items on the front and rear panels of the PJ1000M-C and gives a brief description of each of them. 7.1 Front Panel [1] MORE Green LED, reserved for future use [2] LOCK... -
Page 24: Rear Panel
Mains inlet [10] MAIN SWITCH Mains switch [11] INTRLK IN BNC input connector to disable the PJ1000M-C in case of alarm. This is enabled with the menu “EXT INTERLOCK” [12] AIR FLOW Output for the power supply airflow [13] RS 485... -
Page 25: Modules Identification
PJ1000M-C 7.3 Modules identification [1] Telecontrol/Telesignalling board [2] Blowe control board [3] Blower - RF section [4] Low pass filter and directional coupler [5] 4 - ways combiner [6] RF amplifier modules [7] 4 - ways splitter [8] RF input and alarms board... -
Page 26: Connectors Description
PJ1000M-C 7.4 Connectors description 7.4.1 Telemetry connector Type: DB25 Female Inpute reflected power measurement Power supply voltage measurement Reflected power measurement Interlock output Not used (reserved) “On” command, available when in “remote” mode. Pulse 100 ms to ground to give the command... -
Page 27: Technical Specifications
PJ1000M-C 8 Technical Specifications 8.1 Physical specifications Size 132 mm H (3HE) 483 mm W (Standard 19”) 600 mm D Weight < 20 Kg -10 °C ÷ 50 °C Temperature range 8.2 Electrical specifications AC power supply 230 Vac +/- 10%, 50-60 Hz, with PFC Frequency range 87.5 –... - Page 28 PJ1000M-C This page was intentionally left blank 24 / 24 Rev. 1.1 - 10/11/03 User Manual...
