Analytical Balance
Instruction Manual
For questions or concerns, e-mail service@ussolid.com, visit
www.ussolid.com, or call (800) 243-5428

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1004 and is the answer not in the manual?

Questions and answers

Summary of Contents for U.S. Solid 1004

  • Page 1 Analytical Balance Instruction Manual For questions or concerns, e-mail service@ussolid.com, visit www.ussolid.com, or call (800) 243-5428...
  • Page 2: Operation

    1. INTRODUCTION 2. PREPARATION 3. CALIBRATION single- point calibration internal calibration weight value setting linearity calibration 4. OPERATION piece counting percent weighing unit conversion density determination baud rate dynamic weighing print setting sensitivity setting filter level setting time setting interface 5.
  • Page 3 1. INTRODUCTION 1. INTRODUCTION This analytical balance works on electromagnetic force compensation technology and micro processor which implements high speed stabilization and high reliability. It can be widely used in industry, agriculture, commerce, schools, scientific research and other institutions to quickly weighing the quality and quantity of objects.
  • Page 4: Display Information

    Data sheet DISPLAY INFORMATION Electronic Analytical Balance(0.1mg external calibration) 2004 3204 Model 1004 1204 2204 3004 4204 5204 Capacity 0--100g 0--120g 0--200g 0--220g 0-300g 0--320g 0-420g 0-520g Readability 0.1mg Stable time Preheating 30-60 mins Weighing units g/oz/ct/mg 0.1mg Min weighting Repeatability ±0.1mg...
  • Page 5: Data Sheet

    Data sheet Data sheet Electronic Analytical Balance(0.01mg external calibration) Electronic Analytical Balance(1mg external calibration) 10035 10085 20035X Modle 20003 Model Model 10055 20055 20085 1003 2003 3003 5003 6003 10003 Capacity Capacity 0--100g 0--200g 0--300g 0--500g 0-600g 0--1000g 0--2000g 100g/30g 100g/50g 100g/80g 200g/30g...
  • Page 6 3. CALIBRATION 2. PREPARATION In order to get accurate weighing result, balance should be Put the balance on the stable desk, the desk can not be moved. calibrated before the below usage scenarios. Adjust the 2 Leveling Feet on the bottom, until the bubble is Before first use centered in the circle, then install the scale pan.
  • Page 7 3. CALIBRATION internal calibration weight value setting Single-point calibration follow the sequence (internal calibration balance) press the button“TARE”, the display shows “0.0000”. choose the calibration“CAL-2”(follow 3.2.2) press “CAL” button, the display shows“CAL-DN” press“CAL”button, balance enters into calibration procedure, the display shows“CAL--0”, internal calibration balance will make the calibration automatically put on the standard calibration weight accordingly the display shows “CAL-UP”, remove the weight.
  • Page 8: Unit Conversion

    3. CALIBRATION 4. OPERATION Linearity calibration Unit conversion Balance without loading, and display shows “0.0000”, it can be operated for linear calibration. under the weighing interface press and hold “PRINT” to change the unit the default unit:g,oz,ct,mg press and hold “ON” button, balance enters into main menu mode, start to change function wait to the display shows "SET-C", release the “ON”...
  • Page 9: Percent Weighing

    4. OPERATION density weighing Density determination (need gravity kit, optional) Piece counting weighing setting press and hold “PRINT”button under weighing interface, the display shows “0 PCS”and press and hold “ON” button, the balance enters into the main menu mode. , release the "PRINT" button when the display shows“SET-d”, release the button.
  • Page 10: Solid Density Determination

    OPERATION dynamic weighing setting Solid density determination: Dynamic weighing function press and hold“ON”button under weighing interface, the balance set up auxiliary liquid density value enters into the main menu mode. release the “ON” button until the display shows“SET-5”, press and hold“ON”button under , balance will enter into the main menu and change release the “ON”button until the display shows “SEt-d”, press and hold “CAL”button, enter into auxiliary liquid density value setting...
  • Page 11: Print Setting

    4. OPERATION dynamic weighing Dynamic weighing function Print setting press and hold“ON”button under weighing interface, the balance enters put the sample on the pan. into the main menu mode. press and hold“PRINT”above 3 seconds, will flash, the dynamic weighing starts. release“ON”button until the display shows “SET-P”, stop flashing, weighing end, display shows the final result.
  • Page 12: Sensitivity Setting

    4. OPERATION sensitivity setting Filter level setting press and hold“ON”button under weighing interface, the balance enters press and hold“ON”button under weighing interface, the balance enters into the main menu mode. into the main menu mode. release“ON”button until the display shows “SET-A”, release“ON”button until the display shows “SET-1”, press and hold“PRINT”button to enter into filter level setting, the display shows“-Int- press and hold“PRINT”to enter into sensitivity setting, display shows “-ASD-*-”.
  • Page 13: Time Setting

    4. OPERATION Time setting Interface RS232 interface press and hold“ON”button under weighing interface, the balance enters into the main menu mode. - Connection release“ON”button until the display shows “SET-T”, Balance (9 pins) PC/Printer (9 pins) RXD (Input) TXD (Output) GND (Ground) - The baudrate by default is 9600 bps (see Baudrate setting) - Data format: 10 bits, 0 as start bit, 1 as stop bit, 8 digits (ASCII code) - No odd and even numbers adjusting...
  • Page 14 5.TROUBLESHOOTING Problem Cause Solution Plug in adapter; Change the fuse; No power supply; Change the power transformer; No display Fuse damaged; If problem persists, send the Power transformer is damaged; balance to the Technical Service for repair. Improve the working condition, Bad working conditions;...
