ASSEMBLY INSTRUCTIONS
SKU: DMT
Description
Dimension
Product
Cube Size : 44"x26.7"x3.1"
(TOP)
Cube Size : 25.5"x9"x6"
(PEDESTAL)
Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. Please take the time to read and follow the
assembly instructions carefully.
Be sure to check all packing material carefully for small parts which may have come loose inside the carton during shipment. Please separate, identify, and count all parts
and metal hardware. Compare with part list to be sure all parts are present.
If hardware is missing or you have difficulty assembling this product, please call for us.
IMPORTANT NOTE:
-
Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched.
-
Remove all wrapping material, including staples & packing straps before you start to assemble.
NEW DUBLIN SMALL PEDESTAL
NEW DUBLIN SMALL PEDESTAL
:
42"x29"1/2.H
Ф
BEFORE ASSEMBLY
- 1 -
175 Southbelt Industrial Dr,
Email:sales@eastwestfurniture.net
NW: 28.6 LBS
GW: 31
NW: 12.1 LBS
GW: 14
Houston, TX 77047
LBS
LBS
