ASSEMBLY INSTRUCTIONS
SKU: NDT
Description :
Norden Rectangular Table with Dual Drop Leaf
Product Dimension : 30"/48"x30"x30"
Cube Size : 35.8"x 35.8"x6.8"
Norden Rectangular Table with Dual Drop Leaf
175 Southbelt Industrial Dr,
Email:sales@eastwestfurniture.net
NW: 44
LBS
GW: 52.8 LBS
Houston, TX 77047
Advertisement
Table of Contents
Related Manuals for East West Furniture Norden NDT
Summary of Contents for East West Furniture Norden NDT
- Page 1 ASSEMBLY INSTRUCTIONS SKU: NDT 175 Southbelt Industrial Dr, Houston, TX 77047 Email:sales@eastwestfurniture.net Description : Norden Rectangular Table with Dual Drop Leaf Product Dimension : 30”/48”x30”x30” Cube Size : 35.8”x 35.8”x6.8” NW: 44 GW: 52.8 LBS Norden Rectangular Table with Dual Drop Leaf...
- Page 2 BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. Please take the time to read and follow the assembly instructions carefully. Be sure to check all packing material carefully for small parts which may have come loose inside the carton during shipment. Please separate, identify, and count all parts and metal hardware.
- Page 3 HARDWARE LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the following hardware: Description Sketch Description Sketch Bolt Lock washer (M8x70) ( F8.5xF13mm) Flat Washer Allen key (F8.5x19mm) (M4mm) Screw...
- Page 4 STEP 2 Attach the four legs (B) to the center piece top with Bolts (1) and washers (2), (3). Tighten with Allen Key Norden Rectangular Table with Dual Drop Leaf...
