ASSEMBLY INSTRUCTIONS
SKU: NLF
Description
Product Dimension : 59"Wx84"Lx41.3"H
(FULL BED)
Cube Size
Product Dimension : 65"Wx89"Lx41.3"H
(QUEEN BED)
Cube Size
Nolan Fabric Bed (Full-Queen)
:
Nolan Fabric Bed (Full-Queen)
: 60.9"x35"x5.9"
: 66.8"x35"x5.9"
- 1 -
175 Southbelt Industrial Dr,
Houston, TX 77047
Email:sales@eastwestfurniture.net
NW: 88
LBS
GW: 94.6
LBS
NW: 94.6
LBS
GW: 103.4
LBS
Advertisement
Related Manuals for East West Furniture NLF
Summary of Contents for East West Furniture NLF
- Page 1 ASSEMBLY INSTRUCTIONS SKU: NLF 175 Southbelt Industrial Dr, Houston, TX 77047 Email:sales@eastwestfurniture.net Description Nolan Fabric Bed (Full-Queen) Product Dimension : 59”Wx84”Lx41.3”H (FULL BED) Cube Size : 60.9”x35”x5.9” NW: 88 GW: 94.6 Product Dimension : 65”Wx89”Lx41.3”H (QUEEN BED) Cube Size : 66.8”x35”x5.9”...
-
Page 2: Before Assembly
BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. Please take the time to read and follow the assembly instructions carefully. Be sure to check all packing material carefully for small parts which may have come loose inside the carton during shipment. Please separate, identify, and count all parts and metal hardware. - Page 3 STEP 1 Attach the legs (E) to the bottom of the headboard (C). as shown below. STEP 2 Attach the legs (E) to the bottom of the footboard (D).as shown below. STEP 3 Assemble the Side rails by joining the (A) & (B) side rail using Center support leg (G), and Short Bolts (2), Tighten with Allen key (6).
- Page 4 STEP 4 Attach the Headboard to the assemble side rails using Medium bolts (1) and Washers (4) and Lock Washers (5) on the both sides. Repeat for the Footboard. Tighten with Allen key (6). STEP 5 Attach U-bracket (K) to the Horizontal support frame (H) Tighten with Allen key (6) using Long bolts (3) STEP 6...
- Page 5 STEP 7 Attach Center Support Rail (L) to Headboard & footboard (on step 6) using the Short bolts (2) & Long bolts (3) Tighten with Allen key (6) STEP 8 Place the Slats (F) on the bed frames, and complete the assembly. Nolan Fabric Bed (Full-Queen) - 5 -...
