UBI EasyCoder 71 – Programming
STATUS & CONFIGURATION COMMANDS
U
Print Current
Configuration
UP
Print Codepage & Memory
Status
UM
Codepage & Memory
Status
UI
Codepage Status &
Enable Prompts
FI
Print Form Information
GI
Print Graphics Information
Used for: Direct Mode
Syntax: U
Prints a list with information identical to the first label produced in
the Test Mode (see page 11).
Example: U
Used for: Direct Mode
Syntax: UP
Print the same list as U plus returns a string to the host on the serial
channel with the Codepage & Memory status (see UM).
Example: UP
Used for: Direct Mode
Syntax: UM
Returns a string to the host on the serial communication channel
with the Codepage & Memory status.
Example: UM
Used for: Direct Mode
Syntax: UI
Returns a string to the host on the serial communication channel
with the Codepage status, and also presets the printer to return
variable and counter prompts back to the computer on the serial
interface (new UI instruction must be issued after each power up!).
Example: UI
Note: The optional Keyboard Display Unit sends this command
automatically, as it requires these prompts for its display functions.
If the device used is not programmed to handle prompts, make sure
not to send any UI command during normal use.
Used for: Direct Mode
Syntax: FI
Prints a list of all stored forms and the number of bytes remaining
in the Form memory.
Example: FI
Used for: Direct Mode
Syntax: GI
Prints a list of stored graphics files and remaining graphics memory.
Example: GI
46
