UBI EasyCoder 71 – Specifications

PAPER DIMENSIONS

Paper Roll

Core:
Diameter ...................... :
Width .......................... :
Roll:
Max. diameter .............. :
Max. web width ........... :
Min. web width ............ :
1
Max. web thickness
.........
1
/. This is the recommended maximum thickness. Thicker web may be used
at the possible expense of an impaired printout quality. However, the
stiffness is also important. A stiff web limits the maximum thickness and vice
versa.
Labels should be wound with the labels facing outwards and unroll
from the top of the roll.
Tags should be wound with the thermal-sensitive layer facing
inwards and unroll from the bottom of the roll.
Important! Protect the paper stock against sand, grit, and other
hard particles during printing and storage. Keep the transparent
cover closed. Even very small but hard foreign particles may
cause severe harm to the delicate printhead.
38.1 mm (1.5")
Must not protrude outside the web.
90 mm ( 3.54")
108 mm ( 4.25")
25 mm ( 1.0")
: 175 m (0.007")
