Chapter 4 — Maintenance and Troubleshooting

Cleaning

Th e cutter mechanism becomes accessible when the cover is opened.
Th e cutter shears will need to be cleaned from adhesive residue if the
cutter has been used for cutting through labels, something that is not
advisable. Use isopropyl alcohol (see warning text on the container), but
be careful only to apply it where there is any adhesive residue so you do
not dissolve the lubrication.
Do not force the spring-loaded anvil blade open more than 5-10 mm
(0.2–0.4 inches), or the spring may be damaged.
Switch off the power or disconnect the cutter before clean-
ing. Keep fi ngers away from cutting parts!
Fingerprint only
If the following errors occur, clean the shears from adhesive residue.
• 1701 "Cutter error1"
A cut has been performed but the shear has stopped on its way back to
home (bottom) position.
• 1702 "Cutter error2"
Th e cutter has failed to cut after several attempt (3 is default) and the
shear has returned to home (bottom) position.
• 1703 "Cutter error3"
Th e cutter has failed to cut and the shear has stopped before returning
to home (bottom) position.
If the cutter cable connector has come loose from DIN connector, Error
37, "Cutter device not found" or Error 1059, "Cutter does not respond" will
occur.
If the microswitch in the cutter assy is faulty, Error 1704, "Cutter open"
will occur, even if the cutter in fact is closed. Contact Service.
IPL only
IPL reports if the cutter has failed to return to home position by display-
ing the message "Open&shut cutter." Follow that instruction. If the error
persists, clean the shears from adhesive residue. If this does not help,
contact Service.
12 EasyCoder PX4/6i & 501/601 XP Cutter Kit Installation Instructions
