EasyCoder 3400e Bar Code Label Printer User's Manual
39
Helvetica Condensed Helvetica
Printer Maintenance Schedule (continued)
Printer Component
Drive roller and tear bar
Media path (not shown)
Edge guide
Upper media guide
Lower media guide
Thermal transfer ribbon
(TTR) assist roller
Self-strip roller
Label gap sensor (not shown)
Label mark sensor (not shown)
Label taken sensor
Pinch roller
TTR assist
P o
w e
roller
r /D
a ta
A le
r t
E m
p t
y /
P a
u s
e
F e
e d
Label taken
/ P
a u
s e
I n t e I n t e
sensor
r m e r m e
c c
3 4
0 0
Tear bar
Drive
roller
Pinch
roller
Printer parts: This illustration shows the printer parts that need to be cleaned. For a
maintenance schedule of each part, see the Printer Maintenance Schedule table earlier
in this chapter.
Chapter 3 — Maintaining the Printer
Maintenance Period
Clean after every five rolls of media. If you are
using hi-tack adhesive, you must clean after every
roll of media. If you are using tag stock or
continuous media, you may want to clean after
every five rolls of media or as necessary. Clean
more often in environments that are harsh or
dusty.
Edge
Thermal
guide
Self-strip
printhead
roller
Upper media
guide
Lower media
guide
3XXXU.032
