Triple Serial Interface Board:

RS 232C (V24) on "uart3:"

776704.01

"uart 3:"

P10

The following hardware strap can be fitted:

P-10 DTR signal:

Pin 1–2

A copy of the flow signal RTS is produced.

Pin 2–3

DTR indicates when the printer is turned on.

There is no external +5V available on "uart3:".
