UBI EasyCoder 101 – Technical Manual
SETUP PARAMETERS, cont'd.
Detection, cont'd.
6 dots/mm (153.9 dpi):
1 dot = 0.165 mm = 6.5 mils
8 dots/mm (203.2 dpi):
1 dot = 0.125 mm = 4.9 mils
Rec. adjustments:
Density: 6 dots/mm 8 dots/mm
Dispensing:
Start adjust: -30
Stop adjust: 30
Tear Off:
Start adjust: -56
Stop adjust: 56
Strip:
Start adjust: -56
Stop adjust: 0
Feed Adjustment:
The feed adjustment contains two parameters, Start adjustment
and Stop adjustment, that will be effected regardless of which
program is run. Such global adjustments can be further modified for
various purposes by the use of
Fingerprint manual) within the currently running program.
Note: It is possible to turn off the label stop sensor for a certain
amount of paper feed, and to override the start adjustment and stop
adjustment setup by means of the UBI Fingerprint statement
, see the UBI Fingerprint manual.
LBLCOND
The Start Adjustment is given as a positive or negative number of
dots:
• A positive start adjustment means that the specified length of
paper web will be fed out before the printing starts. According-
-40
40 ly, the origo is moved away from the forward edge of the copy.
(This has the same effect as a positive
-75 before a
PRINTFEED
75
• A negative start adjustment means that the specified length of
paper web will be withdrawn before the printing starts. Accor-
-75
dingly, the origo is moved towards the forward edge of the copy.
0
(This has the same effect as a negative
before a
PRINTFEED
The Stop Adjustment is set up the same way.
• A positive stop adjustment means that the specified length of
paper web will be fed out after the printing is completed.
Accordingly, the origo is moved away from the forward edge of
next copy. (This has the same effect as a positive
statement after a
• A negative stop adjustment means that the specified length of
paper web will be withdrawn after the printing is completed.
Accordingly, the origo is moved towards the forward edge of
next copy. (This has the same effect as a negative
statement after a
FORMFEED
statement).
statement).
statement).
PRINTFEED
statement).
PRINTFEED
statements (see UBI
statement
FORMFEED
statement
FORMFEED
FORMFEED
FORMFEED
