Definitive Technology Studio 3D Mini Owner's Manual page 2

Contents Connections
What you can do with this unit ........................................ 5
Accessories ......................................................................... 9
Inserting the battery ........................................................ 10
Operating range of the remote control unit ............... 10
Part names and functions ............................................... 11
Sound bar ............................................................................ 11
Subwoofer .......................................................................... 16
Remote control unit .......................................................... 17
Positioning .......................................................................... 19
Positioning the sound bar ............................................... 19
Positioning the subwoofer .............................................. 21
Playback Settings
Connections .............................................................. 22
Connecting a TV ............................................................... 22
Connection 1: TV equipped with an HDMI connector
and compatible with the eARC (Enhanced Audio
Return Channel) or ARC (Audio Return Channel) ...... 23
Connection 2: TV equipped with an HDMI connector
and incompatible with the eARC or ARC / TV equipped
with an optical digital connector ................................. 24
Connection 3: TV equipped with an HDMI connector
and incompatible with the eARC or ARC / TV equipped
with an analog connector .............................................. 25
Connecting a playback device ...................................... 26
Connecting an HDMI device ........................................... 26
Connecting the power cords ......................................... 27
Tips Appendix
2
