3.1 Home Theater Sound Bar and Wireless Subwoofer System
Setup Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Studio Slim and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Definitive Technology Studio Slim

Summary of Contents for Definitive Technology Studio Slim

  • Page 1 3.1 Home Theater Sound Bar and Wireless Subwoofer System Setup Guide...
  • Page 2 What’s in the Box Sound bar Power supply Subwoofer power cord Subwoofer Power cord Optical cable Remote control Literature HDMI cable...
  • Page 3 Setup Place the sound bar For the best listening experience, position the sound bar centered under your TV. You may Sound Bar choose to place it either on a stand or wall mount the speaker below the TV. Connect the sound bar to an AC outlet During startup, you will see multiple light shows.
  • Page 4 Download the Google Home App to setup your sound bar on your Wi-Fi network Download the free Google Home app and follow the in-app instructions to setup the Studio Slim on your Wi-Fi network. For more detailed setup information about Google Home and Chromecast built-in for audio, visit: https://support.google.com/googlehome and https://support.google.com/chromecastbuiltin...
  • Page 5 Connect to your TV Is an HDMI input jack on your TV labeled “ARC”? YES — Use HDMI (ARC) NO — Use Optical HDMI HDMI OPTICAL HDMI HDMI OPTICAL TV OPTICAL NETWORK SERVICE RESET SYNC POWER ONLY HDMI 1 HDMI 2 HDMI 3 SERVICE RESET...
  • Page 6 Turn on your TV and enjoy the Studio Slim Turn on your TV and verify that you are hearing sound from the sound bar. If you do not hear sound and do not see any lights on the front of your sound bar,...
  • Page 7 Functionalities Using your TV remote to control the volume The Studio Slim comes pre-configured to respond to volume and mute commands from the most popular TV remotes including: Samsung, LG, Sony, Vizio and other major brands. All other trademarks, product names, logos and brands referenced herein are the...
  • Page 8 Chromecast built-in compatible speakers in your house at the same time. • Use Google Assistant on a Google Home speaker or other Assistant-enabled device to control music playback on the Studio Slim with voice commands. Listening to music via Chromecast built-in •...

  • Page 9: Remote Control

    Remote Control Power On/Off Mute TV Input Optical Input Master Volume Up Master Volume Down Center Down Center Up Bass Down Bass Up Movie Mode Music Mode Night Mode...
  • Page 10 Sound Bar Controls Front of Studio Slim • Power - Turns the Studio Slim on/off • Source - Switches sound bar inputs • Bluetooth - Initiates Bluetooth pairing • Volume Down - Decreases the master volume • Volume Up - Increases the master volume...
  • Page 11 Back of Studio Slim DC Power Input IR Input IR Repeater Optical Input Service Port TV HDMI ARC...
  • Page 12 Visual LED Indicators (Sound Bar) SOURCE INDICATORS Above is a closeup of the source indicators. TV (HDMI-ARC) OPTICAL BLUETOOTH CHROMECAST BUILT-IN Source indicators will illuminate in different colors to indicate the audio bitstream for non-streaming inputs. PCM CONTENT DOLBY CONTENT DTS CONTENT When streaming over Bluetooth, the 11th LED will always remain blue irrespective of the content.
  • Page 13 MUTE INDICATOR While MUTE is active, the source indication will blink. VOLUME LEVEL INDICATORS Master Volume will be indicated with 10 LEDs. Each LED will have 10 levels of brightness to indicate 1-100% volume. Volume 1% will be indicated with the left most volume dimly lit, volume 100% will be indicated with all 10 volume LEDs fully illuminated.
  • Page 14 Optimize Your Listening Experience CENTER Less DEFAULT More CENTER LEVEL CENTER Customize the voice level to reproduce clear, crisp dialogue on your sound bar using the center (+/-) button on your sound bar remote. BASS Less DEFAULT More BASS LEVEL BASS Customize the bass (or low frequency output) level using the bass (+/-) buttons on your...
  • Page 15 Using Your TV or Cable/Satellite TV Remote to Control the Studio Slim There are several ways to use your TV, cable, or satellite remote to control the Studio Slim. HDMI CEC CONTROL If your TV is connected via HDMI and your TV supports CEC (and it is enabled in the TV settings menu), you can control the volume and mute functions on the Studio Slim from your TV without any further setup.

  • Page 16: Sound Modes

    Sound Modes Music Mode Music mode provides a natural and balanced sound profile with smoother bass while minimizing home theater spatialization effects. NIGHT MODE Movie Mode Movie mode is optimized for both movies and TV content. It provides home theater spatialization effects, as well as enhanced dialogue and more dynamic bass impact.
  • Page 17 For Further Assistance: Phone Number (800) 228-7148 (North America) +1 (410) 363-7148 Email info@definitivetech.com Mail Definitive Technology 1 Viper Way Vista, CA 92081...
  • Page 18 1 Viper Way Sound United Europe Vista, CA 92081 a division of D&M Europe B.V. 800-228-7148 Beemdstraat 11 www.definitivetechnology.com 5653 MA Eindhoven The Netherlands HBP4236...
