- Page 1 Studio 3D Mini 4.1 Home Theater Sound Bar and Wireless Subwoofer System Setup Guide...
-
Page 2: What's In The Box
What’s in the Box Sound bar HDMI cable Subwoofer Power cords Optical cable Wall mount spacers Wall mount template Literature Remote control Two AAA batteries... - Page 3 TV. You may choose to place it either on your furniture, or wall-mount the sound bar below the TV. OPTIONAL: The Studio 3D Mini can be wall mounted. Please refer to the wall mount template in the product carton.
- Page 4 Connect the subwoofer to an AC outlet and switch power to ON Subwoofer SYNC LED On the back of the subwoofer, the SYNC LED will be solid green to indicate that it is paired to the sound bar. Download the HEOS App Download the HEOS App on your iOS or Android Device.
- Page 5 Tap “Add Device” in the Settings Screen Settings Add Device Follow instructions in App to complete the setup and configuration of Studio 3D Mini. Owner’s Manual For more information, visit https://www.definitivetechnology.com/. Refer to the Online Manual for other functions information and operation procedure details.
-
Page 6: Remote Control
Remote Control Bluetooth Power On/Off Mute TV Input Auxilary Input HDMI Input Optical Input Master Volume Up Dialogue Enhancer - Adjust the volume of dialog in movies, vocals in music, etc. Master Volume Down so these can be heard more easily. Subwoofer Down Subwoofer Up Music Mode... - Page 7 (See on page 8.) Status LED - Shows current sound bar status. (See pages 9 and 13.) • Power - Turns the Studio 3D Mini on/off • Source - Switches sound bar inputs • Bluetooth - Initiates Bluetooth pairing •...
- Page 8 Back of Studio 3D Mini Power Optical HDMI IN Ethernet Sync Button HDMI OUT Connect Button (eARC/ARC) - Used to wirelessly - Used for Wi-Fi setup. connect the sound bar and subwoofer. Connect/Sync...
- Page 9 Sound Bar Indicators and Status Lights Visual Indicator LEDs Status LED Source Indication Below is a table showing the source indicators. HDMI OPTICAL BLUETOOTH HEOS Several source colors indicate the audio bitstream for non-streaming inputs. PCM CONTENT DOLBY SIGNAL DTS SIGNAL NOTE: “TV”...
- Page 10 Volume Indication Master Volume will be communicated with the five LEDs in the row of Visual Indicators LEDs. Volume of 1% will be indicated by the leftmost LED as dimly lit, and 100% will be indicated with all 5 Visual Indicator LEDs fully illuminated. Visual Indicator LEDs Visual indicator LEDs will illuminate purple NIGHT MODE - enabled...
- Page 11 Subwoofer Back Panel & Visual LED Indicators Back Panel of Subwoofer SYNC LED - Indicates connection status between sound bar and subwoofer. SYNC Button - Used for troubleshooting or resetting the connection between the sound bar and subwoofer. Power Switch Power...
- Page 12 3. Select “Studio 3D Mini” from the list of available Bluetooth speakers from your mobile device. 4. Play music using any app on your device and the sound will now play from the speaker.
-
Page 13: Basic Troubleshooting
Basic Troubleshooting MY SOUND BAR WON’T CONNECT TO MY NETWORK - Make sure your mobile device is connected to your wireless network before setting up your sound bar. - Alternatively, you can connect your sound bar to your network router using an Ethernet cable sold seperately. - Page 14 NO SOUND COMING OUT FROM THE SUBWOOFER - Ensure that your subwoofer is connected to power and switched ON. - Check the SYNC LED at the back of the subwoofer. Make sure that it is solid green. If it is not green, refer to the online manual for detailed instructions on how to manually reset the connection between the sound bar and subwoofer.
-
Page 15: For Further Assistance
+1 (410) 363-7148 Email definitive@custhelp.com Mail Definitive Technology 15541 Fermi Court Carlsbad, CA 92008 U.S.A Warranty This sound bar is covered by a limited warranty. Details can be found on the Definitive Technology website: https://www.definitivetechnology.com/warranty-information Follow us on Twitter Instagram Facebook... - Page 16 www.definitivetechnology.com Printed in Vietnam 5411 11892 00AT © 2020 Sound United. All Rights Reserved.
