Serta SHELBY Assembly Instructions

OPERATING THE SHELBY

Standing at the side of the unit (from bed position), lift backrest to the desired position and secure in

place by releasing to the sound of a click.

IMPORTANT: During conversion, ensure lifting is done from the back of backrest.

From sofa or lounge position, lift backrest all the way upwards until the last click is heard which unlocks

the mechanism and carefully return to a flat position.

Ensure unit is in bed position. Facing sofa, lift right side of sofa seat (and backrest) to the desired chaise

position.

SHELBY

TOLL FREE 1-866-626-7826 LIFESTYLE SOLUTIONS

4 of 4

Rev.141126

Table of Contents

Do you have a question about the SHELBY and is the answer not in the manual?

Page 1 OPERATING THE SHELBY Converting to Sofa or Lounger Standing at the side of the unit (from bed position), lift backrest to the desired position and secure in place by releasing to the sound of a click. IMPORTANT: During conversion, ensure lifting is done from the back of backrest.
Page 2 3. Secure each leg with two bolts fastened using rivet nut with the provided Allen keys. Sofa body 4. Finally, lift and turn assembled unit onto its legs. A flat configuration of the sofa indicates that it is in bed position (refer Operating The Shelby on page 4). 2 of 4 3 of 4...
