- Page 1 Cosset Series Big & Tall Executive Chair Assembly Instructions Model SRJ-48964 400 lbs...
- Page 2 PARTS Casters Star Base Gas Lift with Telescoping Cover Seat Plate Quantity: 5 Quantity:1 Quantity: 1 Quantity: 1 Left Arm Right Arm Seat Cushion Back Cushion Quantity: 1 Quantity: 1 Quantity: 1 Quantity: 1 1-1/2” Big Screws 1” Big Screws 1-1/4”...
- Page 3 Step 1 Place the Star Base (B) upside down and insert 5 Casters (A) into the holes on the Star Base (B). Step 2 Turn the Star Base (B) over and insert the Gas Lift with Telescoping Cover (C) through the center hole on top of Star Base (B).
- Page 4 Step 3 Attach Seat Plate (D) to the bottom of the Seat Cushion (F) (with the front of the seat plate facing the front of seat cushion). Attach by using 1-1/2” Big Screws (H) for the front holes of the Seat Plate (D) and 1”...
- Page 5 Step 5 Fasten the Arms (E1 & E2) onto sides of the Seat Cushion (F) by using 1-1/4” Small Screws (J). *Note: Do not tighten the screws completely. Step 6 Place the Back Cushion (G) flat between Arms (E1 & E2), and use 1-1/4”...
- Page 6 Step 7 Push the Back Cushion (G) up to a vertical position and attach the Arms (E1 & E2) by using 1-1/4” Small Screws (J). *Note: Tighten all the screws completely. Step 8 Press the Plastic Caps (K) into armrest holes once all screws have been tightened.
-
Page 7: Function Instruction
Operating Instructions Function Instruction - 1 To Adjust Seat Height: While seated, lean forward and reach under the right side of the chair to find the handle. Lift the handle and raise your body up slightly to allow the chair to rise to the desired height. - Page 8 Function Instruction - 3 To Adjust Tension On The Tilt: Reach under the front center of the chair, grasp the round knob (R) and turn it counter- clockwise to stiffen the tilt mechanism for a heavier user. Turn the knob (R) clockwise to loosen the tilt mechanism for a lighter user.
- Page 9 Function Instruction - 4 Featuring Pivot Reactive Ergonomic Support System: While seated, the pivot reactive lumbar can dynamically provide continuous support by connecting with your body’s natural movement. The pivot reactive lumbar conforms to the curve of your spinal cord and is intended to relieve your back from stress at any back angle.
- Page 10 Function Instruction - 5 360˚ Swivel: 360˚ seat swivel.
