- Page 1 Assembly Instructions Serta Works Office Chair So comfortable, you’ll feel the di erence the moment you sit down.
- Page 2 Should you prefer to speak with a customer service representative, you may call toll free : 1-855-372-2315 U.S. 6am - 5pm PST, 0-800-051-6775 U.K. 2pm - 1am...
- Page 3 Guidelines FAILURE TO FOLLOW THESE WARNINGS WHEN IN USE COULD RESULT IN INJURY Do not stand on the item or use as a step ladder • • The piece has been tested and approved for users weighing up to 250 lbs (113kg) per seat. Do not use this item unless all bolts and screws are •...
- Page 5 (1) Casters x 5 (2) 5 Star Base x 1 (3) Gas Lift x 1 (4) Telescoping Cover x 1 (5) Left & Right Arm (6) Seat Cushion x 1 (7) Seat Plate x 1 (8) Back Cushion x 1 (9) M6x35MM x 6 (10) M6x20MM x 4 (11) M6x45MM x 4...
- Page 6 1. Ensure all parts have been removed from the carton and place on a protected surface or carpet. 2. Check all parts and hardware are the same as the “Parts List”. 3. To begin assembly, place 5 Star Base (2) upside down and insert Casters (1) into bottom of Base (2).
- Page 7 Fasten Arms (5 L & 5 R ) onto sides of Seat Cushion (6) by using M6x35 MM Screws (9). Then fasten with Allen Key (12). (12) (9) x 3 (9) x 3 (5 L&R...
- Page 8 Attach Seat Plate (7) onto the bottom of Seat Cushion (6) (with front of seat plate facing front of seat cushion) by using M6X20MM Screws (10) in the holes of Seat Plate (7) and tighten screws with Allen Key (12). (10) x 4...
- Page 9 Step 4-- Place the Back Cushion (8) Between Arms (5), and use M6X25MM Screws (11) to locate screw holes on both Arm (5) & Back Cushion (8) as Diagram. Tighten all screws by Allen Key (12). (11) x 2 (11) x 2...
- Page 10 Step 5-- Place the assembled Seat Cushion (6) with Seat Plate (7) on top of Gas Lift (3) and press down until fully engaged.
- Page 11 Step 6-- Periodically (every 90 days) make sure that the screws are still fully tightened. ATTENTION: Be certain that all screws are fully tightened before using chair.
- Page 12 OPERATING INSTRUCTIONS To Adjust Seat Height: To Operate Tilt Lockout: While seated, reach the right side of the chair to While seated, reach under the right side of the find the handle. Lift and raise your body up chair to find the height adjustment handle. Pull slightly to allow the chair to rise to the desired the handle all the way out (away from the gas height.
- Page 13 To Adjust Tension on the Tilt: Reach under the front center of the chair, grasp the round knob and turn it counter-clockwise to stiffen 360˚ Seat swivel. the tilt mechanism. Turn the knob clockwise to loosen the tilt mechanism. Rotate the knob until the desired resistance is reached.
-
Page 14: Product Dimension
35- 38.9 Inch 88.9- 98.8 cm 22.4 Inch 23.2 Inch 56.9 cm 59 cm Product Dimension... -
Page 15: Limited Warranty
Limited Warranty The exceptions or exclusions to this warranty are: • Upholstery material and foam cushion material is The product you have purchased is warranted against warranted against defects in material and workmanship defects in material and workmanship while owned by for a period of one year, beginning on the date of the “Original Purchaser”.
Need help?
Do you have a question about the Works and is the answer not in the manual?
Questions and answers
The casters will not stay in and keep falling off
To fix casters that keep falling off your Serta Works chair:
1. Turn the 5 Star Base (part 2) upside down.
2. Insert the Casters (part 1) firmly into the holes at the bottom of the Base.
3. Make sure each caster is pushed in completely until it clicks or feels secure.
4. Turn the base right side up and test each caster to ensure it is tightly fitted.
If casters continue to fall out, inspect for damage or wear and consider replacing them.
