  • Page 1 CFP-500 CFP-500 Dual Line Dialer Installation Manual · · Version 1.0 WARNING: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read.

  • Page 2: Table Of Contents

    4.2 DLS Programming..........12 1.3 Technical Support and General Information ....2 4.3 Panel Programming Section Descriptions....12 Section 2: Installing and Wiring the CFP-500 ....3 Section 5: Programming Worksheets ......16 2.1 Unpacking the CFP-500.......... 3 5.1 Dialer Programming Worksheets......16 2.2 Wiring the CFP-500..........

  • Page 3: Section 1: Introduction

    Section 1: Introduction The CFP-500 is a dual line dialer that will communicate all alarms, supervisory and trouble conditions to a Central Station using Contact ID, SIA or 10/20 bps communication formats. The CFP-500 will support the CFP-102 or CFP-105 Fire Panel. The CFP-550 Handheld Programmer must be used to program the CFP-500 Dialer.

  • Page 4: Technical Support And General Information

    1.3 Technical For technical support from DSC: Call toll free 1-800-387-3630 (Canada & US) Support and For general product information visit our web site: www.dsc.com General 1.3.1 System Verification Information The complete fire alarm system must be verified for proper installation and operation when: •...

  • Page 5: Section 2: Installing And Wiring The Cfp-500

    CFP-500 charts. The current rating for the CFP-500 is: • 40 mA standby current • 65 mA alarm current (when dialing) 2.2.1 Mount the CFP-500 The CFP-500 is located inside the main panel cabinet according to the following diagram: firealarmresources.com...
  • Page 6 2.2.2 Connect the CFP-500 The CFP-500 requires connection of the Secur-bus from the dialer to the main panel using the provided 4-pin polarized locking cable assembly. Up to two telephone lines are connected to the Tip/Ring/T1/R1 terminals. Connect the dialer according to the following diagram:...

  • Page 7: Section 3: Cfp-500 Operation

    Section 3: CFP-500 Operation 3.1 LED Indicators The dialer’s operating status is visible from its five LED indicators. These indicators are located on the dialer. Each indicator is described in the following table: Indicator LED Color Activates when... Secur-bus Fault...

  • Page 8: Section 4: Programming The Cfp-500

    Refer to the wiring diagram in “Con- CFP-550 nect the CFP-500” on page 4 for the location of the RJ-11 jack. Handheld Once the programmer is connected, it will power up and remain idle until programming is initiated.
  • Page 9 C F P - 5 0 0 R O G R A M M I N G T H E Dialing Options, Section [051]-[052] The options in programming sections [051]-[052] are explained below. Where applicable, other sections of the manual will be referenced for more information regarding the feature. The default setting for each option (ON or OFF) is indicated with an *.
  • Page 10 *OFF = DLS Callback Disabled. When the remote computer connects to the dialer communications will begin. • [8] DLS Double Call ON = DLS Double Call Enabled. If there is more than 7 seconds delay and less than the programmed DLS Double Call window timer between the first/ second and the second/third ring, the dialer will answer the incoming call.
  • Page 11 C F P - 5 0 0 R O G R A M M I N G T H E Communicator Format Options, Section [021] A 2-digit entry is required for each telephone number. Only one communicator format may be programmed for each telephone number.
  • Page 12 The SIA format communicates information quickly using frequency shift keying (FSK) rather than pulses. The 2-digit reporting code is used to identify the zone. SIA Communicator Options [052] #1-2 If the SIA Sends Automatic Reporting Codes option is selected, the dialer will automati- cally generate a reporting code for each event.
  • Page 13 C F P - 5 0 0 R O G R A M M I N G T H E Reporting Codes, Sections [201]-[270] Unless you are using Automatic Contact ID or Automatic SIA formats, reporting codes must be programmed in order for the panel to report events to the central station. Reporting codes are two digits and can use hexadecimal digits A through F.

  • Page 14: Dls Programming

    4.2 DLS 4.2.1 [401] Number of Rings to Answer On Programming This is the number of rings the dialer requires before answering an incoming call. Ring detect supports Line One only. Programming 000 disables ring detect. Valid entries are 000-255. Default is 012. 4.2.2 [402] DLS Double Call Window This is the maximum amount of time the panel will wait between rings to answer an incoming call with the double call feature.
  • Page 15 C F P - 5 0 0 R O G R A M M I N G T H E 04 Supervisory Classifies the zone as a fire supervisory. All alarms are instant and will turn on the buzzer instead of the bell. Pressing the Trouble Silence Switch silences the supervisory buzzer. If a Supervisory occurs while there is another zone alarm, the Signal Silence switch will silence both the Alarm and Supervisory conditions.
  • Page 16 [6] Walk Test Audible Options ON = Walk test is Audible. On a fire or supervisory alarm the NAC’s will pulse once – ¼ sec. On a zone or system trouble, except ground fault, the NAC’s will sound twice – ¼ ON, ¼ OFF, ¼ ON and OFF. For ground fault the NAC’s will sound three times –...
  • Page 17 C F P - 5 0 0 R O G R A M M I N G T H E 4.3.4 Clock Adjust , Section [091] This 3-digit value is used for any time correction required due to inaccuracies of the crystal time keeper.

  • Page 18: Section 5: Programming Worksheets

    Section 5: Programming Worksheets 5.1 Dialer Programming Worksheets [000] Installer’s Access Code (4 digits) Default 2600 [001] First Telephone Number(32 digits) [002] Second Telephone Number (32 digits) [003] hird elephone umber (32 digits) [011] First Telephone Number Account Code (4 digits) [012] Second Telephone Number Account Code (4 digits) [021] Communicator Format Options 10 bps, 1400 Hz handshake...
  • Page 19 R O G R A M M I N G O R K S H E E T S [034] Maintenance Trouble/Restore Communicator Call Directions Default Option ON Option OFF Options 1-6 Future Use Option 7 Telephone Number 2 Disabled Option 8 Telephone Number 1 Disabled...
  • Page 20 [053] Intertional Communicator Options Code Default Option ON Option OFF Option 1 Force Dialing Enabled Force Dialing Disabled Option 2 Busy Tone Detection Enabled Busy Tone Detection Disabled Option 3 Pulse Dialing Make/Break Ratio is 33/67 Pulse Dialing Make/Break Ratio is 40/60 Option 4 1600 Hz Handshake Standard Handshake...
  • Page 21 R O G R A M M I N G O R K S H E E T S [201] Alarm Reporting Codes, Zones 1-5 Zone 1 Alarm Zone 4 Alarm Zone 2 Alarm Zone 5 Alarm Zone 3 Alarm [217] Alarm Restoral Reporting Codes, Zones 1-5 Zone 1 Alarm Restoral Zone 4 Alarm Restoral...
  • Page 22 [401] DLS Number Of Rings To Answer On Default (Valid entries are 000-255 rings) [402] DLS Double Call Window Default (Valid entries are 000-255 seconds) [403] DLS Download Enable Timer Default (Valid entries are 000-254 seconds) [411] DLS Telephone Number(32 digits) [421] DLS Access Code (4 digits) Default 2600...

  • Page 23: Panel Programming Worksheets

    R O G R A M M I N G O R K S H E E T S 5.2 Panel Programming Worksheets [001] Zone 1-16 Definitions Zone Definitions Null zone (not used) Waterflow Instant Fire Supervisory Verify Fire 4-Wire Verify Fire Default Default Zone 1...

  • Page 24: Section 6: Warranty And Warning Information

    Section 6: Warranty and Warning Information 6.1 Warning Note to Installers This warning contains vital information. As the only individual in contact with system users, it is your Please Read responsibility to bring each item in this warning to the attention of the users of this system. Failure to prop- Carefully erly inform system end-users of the circumstances in which the system might fail may result in over-reliance upon the system.
  • Page 25 A R R A N T Y A N D A R N I N G N F O R M A T I O N someone sleeping if there is an intervening wall or door. If notification appliances are located on a different level of the residence or premise, then it is less likely that the occupants will be alerted or awakened.

  • Page 26: Limited Warranty

    6.2 Limited Warranty Digital Security Controls Ltd. warrants the original purchaser that for a period of twelve months from the date of purchase, the product shall be free of defects in materials and workmanship under normal use. During the warranty period, Digital Security Controls Ltd. shall, at its option, repair or replace any defective product upon return of the product to its factory, at no charge for labor and materials.

  • Page 27: Appendix A: Table Of Reporting Codes

    Appendix A: Table of Reporting Codes The following tables contain automatic Contact ID and SIA format reporting codes. For more information on reporting formats, see Section 4.3.5 “Communicator Format Options”. Contact ID The first digit (in parentheses) will automatically be sent by the control. The second two digits are programmed to indicate specific information about the signal.
  • Page 28 Table 2: Contact ID Zone Alarm/Restoral Event Codes Program any of these codes for zone alarms/restorals when using the standard (i.e. not automatic) Contact ID reporting format: (1)18 Near Alarm Medical Alarms 24 Hour Non-Fire (1)A1 Emergency (1)51 Gas Detected Panic Alarms (1)A2 Fail to Report In (1)2A Panic...

  • Page 29: Appendix B: Table Of Compatible Receivers

    Appendix B: Table of Compatible Receivers Sur-Gard Sur-Gard Sur-Gard Osbourne Silent Ademco Radionics Bell Mobility Format/Receiver MLR2000 Hoffman Knight 6500 Pager Quick Alert II 10 bps (1400Hz handshake) 10 bps (2300Hz handshake) 20 bps (1400Hz handshake) 20 bps (2300Hz handshake) SIA (level 2) Contact ID Pager...
  • Page 30 FCC COMPLIANCE STATEMENT CAUTION: Changes or modifications not expressly approved by the manufacturer could void your authority to use this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 31 firealarmresources.com...
  • Page 32 ©2001 Digital Security Controls Ltd. Toronto, Canada Tech. Line (Canada & US): 1-800-387-3630 • www.dsc.com Printed in Canada 29005860 R002 firealarmresources.com...
