Boiler Manual
Incorporating:
High Efficiency
Condensing Boilers
Models covered by this manual:
U-Series
Utility
Utility Pumped
Utility System
Utility Combi
K-Series
Kabin Pak
Kabin Pak Pumped
Kabin Pak System
Kabin Pak Combi
Leave this manuaL with the end user
Guarantee Registration
User Instructions
Installation Instructions
Service Instructions
Service Record
U70HE
UP70HE
US70HE
UC70HE
K70HE
KP70HE
KS70HE
KC70HE
U90HE
UP90HE
US90HE
UC90HE
K90HE
KP90HE
KS90HE
KC90HE
U120HE
K120HE
Advertisement
Related Manuals for WarmFlow U Series
Summary of Contents for WarmFlow U Series
- Page 1 Boiler Manual Incorporating: Guarantee Registration User Instructions Installation Instructions Service Instructions Service Record High Efficiency Condensing Boilers Models covered by this manual: U-Series Utility U70HE U90HE U120HE Utility Pumped UP70HE UP90HE Utility System US70HE US90HE Utility Combi UC70HE UC90HE K-Series Kabin Pak K70HE K90HE K120HE Kabin Pak Pumped KP70HE KP90HE Kabin Pak System KS70HE...
- Page 2 Servicing To ensure continued reliable operation and fuel economy it is recommended that the boiler is serviced annually by a Warmflow or an OFTEC registered technician. NI Customers Only Warmflow Engineering Service division (NI) provides an excellent back-up service, operating a team of OFTEC trained engineers who can meet all the servicing, commissioning and breakdown requirements for your appliance.
- Page 3 Contents Page User Instructions ..................................2 Condensing Boiler Installation Requirements ........................4 Condensing Combi Boiler Pre-Installation Requirements....................5 1.0 General Information Introduction ..............................6 General Requirements .............................6 Combi General Requirements ..........................7 Baffle Positioning .............................7 Components ..............................8 2.0 Technical Details Combi Sequence of Operation Flow Chart ....................5 Dimensions ..............................6 Flue Options, Components & Dimensions......................8 Condensate Disposal ............................2 Technical Data ...............................22 3.0 Electricity Supply & Wiring Details...
- Page 4 This indicates that there is a fault or there is no fuel getting to the burner. The house holder should only reset the burner twice in succession. If the burner continues to lockout contact Warmflow or your service engineer. System Pressure – System & Combi Boilers...
- Page 5 These switches can be replaced by the optional two channel digital programmer, instructions for use are provided in the main boiler handbook. This boiler must be serviced annually. Contact Warmflow for further details. In the event of a breakdown please contact your commissioning engineer who should then contact our service department whilst at your home, to report the fault.
- Page 6 CONDENSING BOILER INSTALLATION REQUIREMENTS The Warmflow condensing boiler can be fitted to most installations using standard practices and techniques. There are however a number of considerations that must be taken into account. All existing systems must be properly flushed to remove any sediment/ sludge in order to prevent any blockage or reduction in efficiency of the boiler.
- Page 7 That any showers being supplied with hot water by the boiler are compatible with this type of appliance (contact Warmflow for further details). It should be noted that the boiler has been factory fitted with an 8 litre/min flow restrictor.
- Page 8 Regulations Section 6, Part F northern Ireland and Part L Republic of Ireland. Warmflow oil fired condensing boilers are designed to burn Class C2 (28 sec redwood) kerosine and to be used on a fully pumped system, and are suitable for connection to sealed heating systems.
- Page 9 1.3 Combi General Requirements The boiler will have a DHW priority when both domestic hot water (DHW) and central heating (CH) are selected. So if the flow switch is closed or the heat store has not been satisfied the entire output of the boiler is directed to DHW before the boiler will switch over to CH.
- Page 10 1.5 Components 1.5.1 U-Series Utility – Casing Components 1. Boiler Assembly 2. Top Casing (removable) 3. Rear Casing 4. Side Casing 5. Front Casing (removable) 1.5.2 U-Series Utility – Pre-Wired (UHE) – Key Components 1. Heat Exchanger 2. Condensing Unit 3. Auto Air Vent 4. Service Door 5. ‘Dual-Safe’ Thermostat 6. Heat Exchanger Baffles 7. Service Door 8. Service Door Cover 9. Condensate Trap 10. Riello RDB 2.2 Burner 11. Heating Flow Connection 12. Heating Return Connection Page 8...
- Page 11 1.5.3 U-Series Utility – Pumped (UPHE) – Key Components 1. Heat Exchanger 2. Condensing Unit 3. Pipework Assembly 4. Pressure Relief Valve 5. Auto Air Vent 6. Circulating Pump 7. Auto Air Vent 8. Service Door 9. ‘Dual-Safe’ Thermostat 10. Heat Exchanger Baffles 11. Service Door 12. Service Door Cover 13. Condensate Trap 14. Riello RDB 2.2 Burner 15. Heating Flow Connection 16. Heating Return Connection 1.5.4 U-Series Utility – System (USHE) – Key Components 1. Pumped (UPHE) Boiler Assembly 2. System Kit (SK1) 3. Pressure Gauge 4. Expansion Vessel 5. Filling Loop 6. Heating Flow Connection 7. Heating Return Connection Page 9...
- Page 12 1.5.5 U-Series Utility – Combi (UCHE) – Key Components 1. Heat Exchanger 2. Heat Store 3. Condensing Unit 4. Service Door 5. Pipework Assembly 6. Plate Heat Exchanger 7. Twin Head Pump 8. Condensate Trap 9. Service Door 10. Service Door Cover 11. Control Panel 12. Expansion Vessel 13. Riello RDB 2.2 Burner 14. Heat Exchanger Baffles (see dimension drawing for details of connections) 1.5.6 U-Series Utility – Combi (UCHE) – Control Panel Control Mains On High Limit Tripped Burner Lockout Thermostat Lamp (Green) Lamp (Yellow) Lamp (Red) High Limit Thermostat Reset HW On/Off CW On/Off (Underneath) Switch Switch...
- Page 13 1.5.7 K-Series Kabin Pak – Casing Components 1. Boiler Assembly 2. Top Casing (removable) 3. Flue Assembly (removable) 4. Rear Flue Casing 5. Blanking Plug (removable) 6. Rear Casing (removable) 7. Side Casing 8. Front Casing (removable) Page ...
- Page 14 1.5.8 K-Series Kabin Pak – Pre-Wired (KHE) – Key Components 1. Heat Exchanger 2. Condensing Unit 3. Auto Air Vent 4. Service Door 5. ‘Dual-Safe’ Thermostat 6. Heat Exchanger Baffles 7. Service Door 8. Service Door Cover 9. Condensate Trap 10. Riello RDB 2.2 Burner 11. Heating Flow Connection 12. Heating Return Connection 1.5.9 K-Series Kabin Pak – Pumped (KPHE) – Key Components 1. Heat Exchanger 2. Condensing Unit 3. Pipework Assembly 4. Pressure Relief Valve 5. Auto Air Vent 6. Circulating Pump 7. Auto Air Vent 8. Service Door 9. ‘Dual-Safe’ Thermostat 10. Heat Exchanger Baffles 11. Service Door...
- Page 15 1.5.10 K-Series Kabin Pak – System (KSHE) – Key Components 1. Pumped (KPHE) Boiler Assembly 2. System Kit (SK1) 3. Pressure Gauge 4. Expansion Vessel 5. Filling Loop 6. Heating Flow Connection 7. Heating Return Connection 1.5.11 K-Series Kabin Pak – Combi (KCHE) – Key Components 1. Heat Exchanger 2. Heat Store 3. Condensing Unit 4. Service Door 5. Pipework Assembly 6. Plate Heat Exchanger 7. Twin Head Pump 8. Condensate Trap 9. Service Door 10. Service Door Cover 11. Control Panel 12. Expansion Vessel 13. Riello RDB 2.2 Burner 14. Heat Exchanger Baffles (see dimension drawing for details of connections) Page 3...
- Page 16 1.5.12 K Series Kabin Pak – Combi (KCHE) – Control Panel Control Mains On High Limit Tripped Burner Lockout Thermostat Lamp (Green) Lamp (Yellow) Lamp (Red) High Limit Thermostat Reset HW On/Off CW On/Off (Underneath) Switch Switch Page 4...
- Page 17 2.0 Technical Details 2.1 Combi Sequence of Operation Flow Chart Power Timer Calling For Heat Selected Flow Switch Closed DHW Tank DHW Pump Stat Satisfied Only Runs Pump Overrun HW Limit Burner Stat Satisfied Selected Stat Satisfied Stops DHW Pump CH Pump Boiler Limit Press Only Runs Only Runs Stat Tripped Reset Button...
- Page 18 2.2 Dimensions 2.2.1 U-Series Utility (UHE, UPHE & USHE Models) MODEL 865 43 60 666 766 42 04 583 50 86 34 2 865 43 60 666 766 42 04 583 50 86 34 2 865 43 60 666 766 42 04 583 50 86 34 2 2.2.2 U-Series Utility (UCHE Models) 1. Pressure Relief Discharge (15mm) 4. Cold Water Mains (15mm)
- Page 19 2.2.3 K-Series Kabin Pak (KHE, KPHE & KSHE Models) MODEL 43 900 700 773 20 95 6 67 67 705 50 43 900 700 773 20 95 6 67 67 705 50 43 900 700 773 20 95 6 67 67 705 50 2.2.4 K-Series Kabin Pak (KCHE Models) MODEL 900 700 772 20 95 6 67 67 705 50 50 396 209 Page 7...
- Page 20 2.3 Flue Options, Components & Dimensions 2.3.1 HE Low Level Balanced Flue Kit (FBF) Comprising the following four main components. Page 8...
