Residential Reverse
Osmosis System
Model WRO-50-R
Owner's Manual
Manufacturing Numbers:
9720020
System Tested and Certified by WQA
against NSF/ANSI 58, CSA B483, 1
for the reduction of:
Barium, Cadmium, Copper, Cyst,
Hexavalent and Trivalent Chromium,
Fluoride, Lead, Nitrite, Nitrate, Raduim
226/228, Selenium, TDS
Original Instructions
CAUTION: Read all instructions before using the unit.
www.antuneswater.com
P/N 1011597 Rev A 01/21
Advertisement
Table of Contents
Related Manuals for Antunes WATER WRO-50-R
Summary of Contents for Antunes WATER WRO-50-R
- Page 1 Label - QR Code, WRO-50-R Last PCO: PDR00211 Created By: Stephanie Clark Approved By: Date: Antunes See Specifications WRO-50-R Scan with mobile device or enter URL for product and service information. https://tinyurl.com/aja-WRO-50-R NOTES: 1. PRINTED OUT-OF HOUSE AND MUST BE PER ALL SPECIFICATIONS ON THIS DOCUMENT 2.
-
Page 2: Table Of Contents
In Case of Damage ......2 installation or operation of the unit, to provide the latest innovation in filtration Service/Technical Assistance....2 contact Antunes Technical Service at technology. Safety Information ........ 3 +1-877-392-7854 (toll free). Installation ..........3 Fill in this information and have it handy Operation .......... -
Page 3: Safety Information
RESIDENTIAL RO Safety Information Installation Protect from becoming dry Protect from abrasive material y Read and understand all If the membrane dries out, irreversible The membranes must be protected from instructions before installing damage to the membrane may result. abrasive materials like shavings left in a or using the unit. -
Page 4: Specifications
RESIDENTIAL RO Specifications System Dimensions Daily Production 29.8 gpd Rate Model Width (A) Depth (B) Height (C) 14" 6" 16" Recovery Rate 36.5% 9720020 (36 cm) (15 cm) (41 cm) Pressure Drop at 5psi Rated Flow Model Drain must accommodate flow up to: System Weight 30 lbs 9720020... -
Page 5: Performance Data Sheet
RESIDENTIAL RO Performance Data Sheet Performance Claims for Percent Reduction Filter Cartridge Capacities Maximum permissible product Substance water concentration mg/L Maximum Operating Pressure 100 psig (690 kPa) barium Minimum Operating Pressure 40 psig (276 kPa) cadmium 0.005 Maximum Operating Temperature 100°F (38°C) chromium (hexavalent) Minimum Operating Temperature... -
Page 6: Overview
RESIDENTIAL RO Overview The Antunes reverse osmosis drinking Long Reach water system is designed for easy Drinking Faucet installation and maintenance. 3/8" Black You will insure a successful installation tubing from Air Gap to as well as reliable operation by carefully... -
Page 7: Unpacking
NOTE: If any parts are damaged, To install a tube, push it through the collet contact Antunes Technical until it seats firmly past the o-ring seal in Service at +1-877-392-7854. the fitting (approximately 1/2 inch inside the fitting). -
Page 8: Installation
RESIDENTIAL RO Installation Secure Mounting Caution Bracket to wall studs using appropriate Avoid locations where the hardware. system might come in contact with hot water pipes or other hazards. Do not mount above an electrical outlet. The system is Location of System Componets designed to hang from the Mounting Determine the location of the RO system,... -
Page 9: Installation
RESIDENTIAL RO Installation Shutting Off the Water Locate the water shut-off valve for the cold water feed line you choose to use for the supply. Accidentally hooking up the system to the hot supply line will perma- nently damage the membrane. CAUTION Do not hook up the RO system to the hot water line. -
Page 10: Drain Clamp Connection
RESIDENTIAL RO Drain Clamp Connection The drain is for flushing mineral buildup out of the system when operating. y The drain used must not be Drain Pipe blocked or restricted. y This system is designed for use 1/4" Nut 1/4" Screw with the air gap faucet provided. -
Page 11: Faucet Installation
RESIDENTIAL RO Faucet Installation Air Gap Faucet Installation If your refrigerator is greater than 25 feet from your R.O. unit, 3/8" tubing is Once the hole has been drilled place the Drilling the Faucet Hole recommended. Do not use copper tubing chrome washer under the faucet body. -
Page 12: Making The Tube Connections
RESIDENTIAL RO Making the Tube Connections Activating and Rinsing the System Connect the system components using Allow the system to flush and the the supplied tubing. Follow the connec- Slowly open the supply feed valve tank to fill for 12 hours. At the end of tion guideline below. -
Page 13: Sanitizing The System And Lines
RESIDENTIAL RO Sanitizing the System and Lines The plumbing and system should Allow water to flow through the system and out of the open faucet. be sanitized to eliminate possible contamination that may have occurred Close the faucet as soon as water during the installation process. -
Page 14: Maintenance
RESIDENTIAL RO Maintenance Every 2-5 Years Tools and supplies required: y Air Pressure Gauge, 5-40 psi Replace RO Membrane Every 6 Months range (0.3-2.7 bar) with tire valve (Schrader Valve) connection. The RO Membrane should be replaced Replace Filters every 2-5 years. The quality of the water y Source of compressed air coming out of the system, and the water The sediment, carbon prefilters, and... -
Page 15: Troubleshooting
RESIDENTIAL RO Troubleshooting Problem Possible Cause Corrective Action Inlet valve closed / water supply is turned No water. Open inlet valve / turn on water supply. off. If line pressure is below 30 psi install a booster Low water pressure. pump. -
Page 16: Replacement Parts
RESIDENTIAL RO Replacement Parts Parts List (x2) (x3) Item Item Part # Description Qty. Part # Description Qty. 7010027 Supply Feed Assembly 7010028 Air Gap Faucet 7010029 ASO Valve 7010032 Flow Restrictor 7010025 Membrane Housing 7010020 Filter Housing w/ O-ring 7010031 Drain Connector Assembly 7010021... -
Page 17: Performance Verification
RESIDENTIAL RO Performance Verification RO Rejection Calculation RO Recovery Calculation After inital flush, a TDS (Total Dissolved Using a stop watch and graduated Solids) measurement can be taken cylinder (or other calibrated volume), and recorded. This data can be used to measure the product water flow rate and compare to future system data. -
Page 18: Notes
RESIDENTIAL RO Date Date Date Date Next Next Next Changed Changed Next Carbon Changed Sediment Postfilter Changed RO Sediment Carbon Change Postfilter Change Change Change Notes P/N 1011597 Rev A 01/21... -
Page 19: Notes
RESIDENTIAL RO Notes P/N 1011597 Rev A 01/21... -
Page 20: Limited Warranty
Antunes reserves the right to make changes in design or add any improvements on any product. The right is always reserved to modify equipment because of factors beyond our control and government regulations.
