Water Filtration System
Model UFL-420/440 Series
owner's manual
Manufacturing Numbers:
9700465
9700475
System Tested and Certified by NSF
International and WQA against NSF/ANSI
Standard 42 and 53 for the reduction of:
Standard No. 42: Aesthetic Effects
Nominal Particulate Reduction Class I
Standard No. 53: Health Effects
Cyst Reduction & Turbidity Reduction as
verified and substantiated by test data.
System Tested and Certified by WQA
against NSF/ANSI Standard 372
for lead-free compliance
www.antunes.com
P/N 1011055 Rev. G 11/16
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Antunes UFL-420 Series
Summary of Contents for Antunes UFL-420 Series
- Page 1 Nominal Particulate Reduction Class I Standard No. 53: Health Effects Cyst Reduction & Turbidity Reduction as verified and substantiated by test data. System Tested and Certified by WQA against NSF/ANSI Standard 372 for lead-free compliance www.antunes.com P/N 1011055 Rev. G 11/16...
-
Page 2: Table Of Contents
UFL-420/440 WATER FILTRATION SYSTEM TABLE OF CONTENTS Owner Information .............2 Installation ..............10 General ..............2 Unpacking ..............10 Warranty Information ..........2 Equipment Setup .............10 Service/Technical Assistance ........3 Mounting the System ..........11 Important Safety Information ........4 Inlet Water Plumbing ..........11 Important Safety Information ........5 Permeate Line Plumbing .........12 Specifications .............6 Drain Valve Connection ...........12... -
Page 3: Service/Technical Assistance
Serial No.: Mfg. No.: IMPORTANT A.J. Antunes and Co. reserves the right to change specifications and product design without notice. Such revisions do NOT entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment. P/N 1011055 Rev. G 10/16... -
Page 4: Important Safety Information
- Do NOT modify the power supply cord plug. If • This equipment should be serviced by qualified it does not fit the outlet, have a proper outlet personnel only. Contact A.J. Antunes & Co. for installed by a qualified electrician. repair. -
Page 5: Important Safety Information
UFL-420/440 WATER FILTRATION SYSTEM IMPORTANT SAFETY INFORMATION Protect from becoming dry CAUTION If the membrane dries out, irreversible damage to the This equipment is to be installed to comply with Ultra Filter membrane may result. Protect the filter from the basic plumbing code of the Building Officials becoming dry by keeping it wet and sealed at all times. -
Page 6: Specifications
UFL-420/440 WATER FILTRATION SYSTEM SPECIFICATIONS Dimensions Electrical Ratings UFL-420 UFL-440 Model & Voltage Watts Amps Hertz Mfg. No. UFL-420 100–240 50/60 9700465 UFL-440 100–240 50/60 9700475 Electrical Cord & Plug Configurations Kit Model Description Configuration Number DC Power Supply 100 - 240 VAC 0012146 Includes the 4 plug adaptors... - Page 7 UFL-420/440 WATER FILTRATION SYSTEM SPECIFICATIONS (continued) Permeate Outlet Drain Valve Flush Button Mounting Bracket Filter Housing Power Transformer Flow Controller Inlet Figure 1. Components P/N 1011055 Rev. G 10/16...
-
Page 8: Performance Data Sheet
UFL-420/440 WATER FILTRATION SYSTEM PERFORMANCE DATA SHEET Performance Claims for Percent Reduction Filter Cartridge Capacities Maximum Operating Pressure 100 psig (690 kPa) Substance Influent Reduction Minimum Challenge Requirement Maximum Operating Temperature 100°F (38°C) Concentration Reduction Minimum Operating Temperature 40°F (4°C) Maximum Trans Membrane Pressure 45 PSI (3.1 Bar) cyst minimum... -
Page 9: Overview
UFL-420/440 WATER FILTRATION SYSTEM OVERVIEW Overview The UFL system operates in two modes: • Normal Operation Mode • Flush Mode During Normal Operation Mode, water enters the Inlet and flows through the Ultra Filter before exiting the Permeate Outlet as usable product water. During Flush Mode, the Drain Valve opens and water entering the Inlet flushes and cleans the Ultra Filter membrane by removing any debris collecting on the... -
Page 10: Installation
3/4” NPT NOTE: If any parts are damaged, contact A.J. When making a plumbing connection to the system, Antunes & Co. IMMEDIATELY at 1-800-253-2991 or remember to use a back-up wrench on the supporting 1-630-784-1000. plumbing. Always use a good quality, approved pipe Equipment Setup sealant or thread seal tape on pipe threads. -
Page 11: Mounting The System
UFL-420/440 WATER FILTRATION SYSTEM INSTALLATION (continued) Inlet Water Plumbing Mounting the System The Inlet water plumbing line should be 1” NPT or The UFL system comes with a Mounting Bracket to larger. A shutoff valve (not supplied) should be installed mount the system securely. -
Page 12: Permeate Line Plumbing
UFL-420/440 WATER FILTRATION SYSTEM INSTALLATION (continued) Permeate Line Plumbing Drain Line Secure To ensure the highest quality and safest water, it is from System recommended that a check valve (to prevent backflow) 2” (5.1 cm) be installed in the water line after the permeate connec- minimum tion. -
Page 13: Starting The Controller
UFL-420/440 WATER FILTRATION SYSTEM INSTALLATION (continued) Starting the Controller Rinsing the Ultra Filter Cartridge 1. Select the proper AC plug for your electrical outlet The Ultra Filter Cartridge must be rinsed before the sys- and install it onto the power supply. tem is used to remove any air and protective solution. -
Page 14: Sanitizing The System And Lines
UFL-420/440 WATER FILTRATION SYSTEM INSTALLATION (continued) Sanitizing the System and Lines IMPORTANT The plumbing must be sanitized to eliminate possible Commonwealth of Massachusetts Plumbing Code contamination that may have occurred during the instal- 248 CMR shall be adhered to. The use of saddle lation process. -
Page 15: Maintenance
UFL-420/440 WATER FILTRATION SYSTEM MAINTENANCE Replacing the Ultra Filter Cartridge 1. Turn off water to the system by closing the inlet valve. 2. Press the FLUSH button to flush the system and relieve pressure. Repeat several times. 3. Place a bucket under the “T” or cross fitting at the inlet connection to the system. -
Page 16: Changing The Interval Setting
UFL-420/440 WATER FILTRATION SYSTEM MAINTENANCE (continued) Changing the Interval Setting CAUTION Changing the flush interval can cause the Ultra Filter to plug prematurely and may reduce the life of the filter. Consult the factory for more informa- tion. Though not recommended, the Interval Setting on the controller can be changed. -
Page 17: Troubleshooting
UFL-420/440 WATER FILTRATION SYSTEM TROUBLESHOOTING Problem Possible Cause Corrective Action Unit does not have power. The power cord is not correctly Plug power cord in correctly. plugged in. The Control Display is blank. The power cord is not correctly Plug power cord in correctly. plugged in. -
Page 18: Replacement Parts
UFL-420/440 WATER FILTRATION SYSTEM REPLACEMENT PARTS Replacement Parts can be purchased from an authorized dealer. Contact A.J. Antunes & Co. at 1-630-754-1000 or toll free in the United States at 1-800-253-2991. P/N 1011055 Rev. G 10/16... - Page 19 UFL-420/440 WATER FILTRATION SYSTEM REPLACEMENT PARTS (continued) Replacement Parts can be purchased from an authorized dealer. Contact A.J. Antunes & Co. at 1-630-754-1000 or toll free in the United States at 1-800-253-2991. Item Part Description Qty. Item Part Description Qty.
-
Page 20: Limited Warranty
Equipment. 2. A.J. Antunes & Co. reserves the right to make changes in design or add any improvements on any product. The right is always reserved to modify equipment because of factors beyond our control and government regulations.
