Summary of Contents for Antunes UF-216CC
- Page 1 ® UF-216CC Water Filtration System Owner’s Manual Manufacturing Numbers: 9700960 Original Instructions www.antunes.com CAUTION: Read all instructions before using the unit. P/N 1011532 Rev. B 04/20...
-
Page 2: Table Of Contents
Antunes, has partnered with Before Use companies from around the globe to In Case of Damage In Case of Damage produce the UF-216CC Series water Website If any parts are missing or damaged, filtration system. The UF-216CC Service/Technical Assistance problems with the installation or operation... -
Page 3: Safety Information Page
UF-216CC WATER FILTRATION SYSTEM Safety Information Page Maintenance WARNING y Do not use abrasive materials; ELECTRICAL SHOCK HAZARD. Installation they can damage the unit’s Failure to follow the instructions in stainless steel finish. y Read and understand all instructions this manual could result in serious before installing or using the unit. -
Page 4: Specifications
UF-216CC WATER FILTRATION SYSTEM Specifications Dimensions Electrical Ratings Model & Voltage Watts Amps Hertz Mfg. No. UF-216CC 100‒240 50/60 9700960 Electrical Cord & Plug Configurations Kit Model Description Configuration Number DC Power Supply 100 - 240 VAC 0012146 Includes the 4 plug adaptors below... -
Page 5: Unit Overview
Figure 1. Components (Front and Back Views) Operation Overview Caution Changing the flush interval can cause the Ultra Filter to plug The UF-216CC system operates in two modes: prematurely and may reduce the life of the filter. Consult the Normal Operation Mode factory for more Flush Mode information. -
Page 6: Equipment Setup
45 psi (310 kPa). Mounting the System The following tools and supplies are suggested to make the installation easier: The UF-216CC system comes with a Mounting Bracket to mount the system securely. When mounting the system, pay y Screwdriver y Adjustable wrenches... -
Page 7: Equipment Setup (Continued)
UF-216CC WATER FILTRATION SYSTEM Equipment Setup (Continued) Permeate Line Plumbing Drain Line Secure To ensure the highest quality and safest water, it is recom- from System mended that a check valve (to prevent backflow) be installed in the water line after the permeate connection. This will help 2”... -
Page 8: Equipment Setup (Continued)
UF-216CC WATER FILTRATION SYSTEM Equipment Setup (Continued) Sanitizing the System and Lines The plumbing must be sanitized to eliminate possible contami- Rinsing the Ultra Filter Cartridge nation that may have occurred during the installation process. The Ultra Filter Cartridge must be rinsed before the system is One ounce (30 ml) of liquid chlorine bleach (regular bleach, used to remove any air and protective solution. -
Page 9: Equipment Setup (Continued)
UF-216CC WATER FILTRATION SYSTEM Equipment Setup (Continued) Installing and Rinsing the Carbon Element The Carbon Element MUST be rinsed before using the system the first time. Install the new Carbon Element into the Carbon Element Housing. Screw the Carbon Element Housing (containing the Carbon Element) into place on the Carbon Element Head. -
Page 10: Maintenance
UF-216CC WATER FILTRATION SYSTEM Maintenance Replacing the Ultra Filter Cartridge Open the faucet or tap closest downstream to the filtration Drain Port system. Permeate Port Close the Inlet Water Valve and allow the system to Connection depressurize. Place a bucket under the strainer at the inlet connection to the system. -
Page 11: Rinsing/Replacing Carbon Element
UF-216CC WATER FILTRATION SYSTEM Maintenance (Continued) Rinsing and Replacing the Carbon Element Open the faucet or tap closest downstream to the filtration system. Close the inlet water valve and allow the system to de- pressurize. Place a bucket under the strainer at the inlet connection to the system. -
Page 12: Maintenance (Continued)
UF-216CC WATER FILTRATION SYSTEM Maintenance (Continued) Changing the Interval Setting Caution Changing the flush interval can cause the Ultra Filter to plug prematurely and may reduce the life of the filter. Consult the factory for more information. Though not recommended, the Interval Setting on the controller can be changed. -
Page 13: Troubleshooting
UF-216CC WATER FILTRATION SYSTEM Troubleshooting Problem Possible Cause Corrective Action Unit does not have power. The power cord is not correctly plugged Plug power cord in correctly. The Control Display is blank. The power cord is not correctly plugged Plug power cord in correctly. -
Page 14: Replacement Parts
UF-216CC WATER FILTRATION SYSTEM Replacement Parts Note Use only genuine Antunes replacement parts in this unit. Use of parts other than those supplied by the manufacturer will void the warranty. Replacement Parts can be purchased from an authorized dealer. Contact us at 86-512-6841-3637, or toll free in the United States at 1-800-253-2991. -
Page 15: Notes
UF-216CC WATER FILTRATION SYSTEM Notes P/N 1011532 Rev. B 04/20 ®... -
Page 16: Limited Warranty
Equip- ment. Antunes reserves the right to make changes in design or add any improvements on any product. The right is always reserved to modify equipment because of factors beyond our control and government regulations.
