- Page 1 DMS-100 Reverse Osmosis System owner’s manual Manufacturing Numbers: 9700570 www.ajantunes.com P/N 1011393 Rev. A 06/16...
-
Page 2: Warranty Information
All information contained in this manual installation or operation of your system, should be read prior to installing and oper- Service/Technical contact A.J. Antunes & Co. at 1-630-784- ating the system. Assistance 1000, or toll free in the United States at... -
Page 3: Important Safety Information
This equipment should be serviced Protect from high temperatures or by qualified personnel only. Contact abrupt variation in temperature A.J. Antunes & Co. for repair. The maximum operating temperature is Do NOT immerse cord 100°F (38°C). Avoid abrupt variations in tem- or plug in water. -
Page 4: Specifications
SPECIFICATIONS Model & Width Depth Height Operating Mfg. No. Weight DMS-100 12” 7” 14.5” 16 lbs 9700570 (31 cm) (18 cm) (37 cm) (7.3 kg) 13.5” 16” 37 kg Tank Assembly (35 cm) (28 cm) (41 cm) (17 kg) CAUTION... -
Page 5: Performance Data Sheet
PERFORMANCE DATA Performance Claims for Percent Reduction SHEET Minimum % Substance Reduction Filter Cartridge Capacities Total Dissolved Solids (TDS) Minimum Operating 40 psig (276 kPa) Pressure Maximum Operating 100 psig (690 kPa) Pressure Minimum Operating 40° F (4° C) Temperature Maximum Operating 100°F (38°... -
Page 6: Operation
OPERATION Overview Normal Operation Mode During Normal Operation Mode, water Yellow - Drain Green - Feed Water Blue - Tank enters the Inlet and flows through the Filter before exiting the outlet as us- able product water. The drain line runs continuously as long as the system is making water. -
Page 7: Installation
Allow sufficient access for tank NOTE: If any parts are damage, contact Suggested Tools and Supplies for replacement and connections. A.J. Antunes & Co. IMMEDIATELY Installation Do not mount the system or tank at 1-800-253-2991toll free above an electrical outlet. -
Page 8: Drain Valve Connection
Drain Valve Connection Drain Line from Secure The drain is for flushing particle buildup out System of the system during operation. The drain line can be installed one of two ways: 2” (5.1 cm) minimum Install a sufficient length of 1/4” OD tubing (not supplied) from the drain outlet on top of the RO system to the drain. -
Page 9: Inlet Water Plumbing
Inlet Water Plumbing Filtered water from a base filtration system should be connected to the inlet of the RO Yellow - Drain Green - Feed Water Blue - Tank System. Connect 1/2” ID Beverage hose (not sup- plied) to the outlet of the base filtration system. - Page 10 Rinsing the RO System Sanitizing the Plumbing The RO System must be rinsed to remove The plumbing from the RO System any air and protective solution before the must be sanitized to eliminate possible system is used. contamination that may have occurred during the installation process.
-
Page 11: Maintenance
MAINTENANCE Replacing the RO Cartridge NOTE: Always install 2 new Carbon WHITE cartridges after replacing the RO Cartridge. CONNECTOR Turn off water to the system by clos- ON TOP ing the feed water valve. Close the tank valve. Open a valve on the product water line or line to the equipment to de- pressurize the line. - Page 12 Replacing the Carbon Cartridges Sanitization NOTE: Always install 2 new Carbon The downstream plumbing should be cartridges after replacing the sanitized every six months. When neces- carbon. sary, follow the SANITIZING THE PLUMBING procedure in the Installation section of this Turn off the water to the system by manual.
- Page 13 SEMI-ANNUAL TASKS ANNUAL TASK Initial Performance Verification After initial flush, a TDS (Total Dissolved Check Permeate Tank Air Change Carbon and RO Solids) measurement should be taken and Pre-Charge Cartridges recorded. This data can be used to compare to factory test data and future system data. The permeate tank air charge should be Both the Carbon Cartridges and the RO Cartridge Some deviations may occur due to differ-...
-
Page 14: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Corrective Action Inlet/Outlet valves closed. Open the inlet/Outlet valves. System depressurized. Pressurize system. Permeate pump not working. Replace permeate pump. No water comes out of the filter system. Inlet Strainer (if installed) is plugged. Clean or replace Inlet Strainer. RO Cartridge is plugged. -
Page 15: Replacement Parts
REPLACEMENT PARTS Replacement Parts can be purchased from an authorized dealer. Contact A.J. Antunes & Co. at 1-630-754-1000 or toll free in the United States at 1-800-253-2991. Item Part # Description Qty. 7001197 Replacement Carbon Kit, Twin Pack 7001198 Replacement RO Kit,... - Page 16 Feed Feed Product Drain Percent Product Feed Percent Date Temperature Pressure Flowrate Flowrate Recovery Rejection (°F) (psig) (ml/min) (ml/min) (ppm) (ppm) P/N 1011393 REV. A 06/16...
- Page 17 Date Date Changed Next Carbons Changed Next RO Changed Next Carbons Changed Next RO Carbons Change Change Carbons Change Change P/N 1011393 REV. A 06/16...
- Page 18 NOTES P/N 1011393 REV. A 06/16...
- Page 19 NOTES P/N 1011393 REV. A 06/16...
-
Page 20: Limited Warranty
Equipment. A.J. Antunes & Co. reserves the right to make changes in design or add any improvements on any product. The right is always reserved to modify equipment because of factors beyond our control and government regulations. Changes to update equip- ment do not constitute a warranty charge.
