SPECIFICATIONS

Specifications

Performance Specifications

These specifications allow you to compare your Vocaster with other devices and make
sure they'll work together. If you're not familiar with these specifications, don't worry you
don't need to know this information to use your Vocaster with most devices
Sample Rate
48 kHz
USB
Version USB 3.0
Maximum Current 0.8A
Maximum Voltage 5V
Maximum Power 4W
Microphone Input
Impedance 3KΩ
Maximum Input Level +12.5dBu @ minimum gain
Gain Range 70dB
THD+N (@ -1dBFS) ≤-94dB
Frequency Response
20Hz - 20KHz +0, -0.5 dB
(20Hz @ mininum gain)
focusrite.com
.
Phone Input
Impedance 18KΩ
THD+N (@ -1dBFS) ≤-94dB
Maximum Input Level +1dBu
Frequency Response 20Hz - 20KHz +0, -0.5
Phone Output
Impedance 220Ω
Maximum Output
-26dBu
Level
THD+N -73dB
Frequency Response 20Hz - 20KHz +0dB, -0.5dB
Line Outputs
Impedance 440Ω
Maximum Output
+14dBu
Level
THD+N ≤-96dB
Frequency Response 20Hz - 2kHz ±0.15dB
Tell the world
Headphone Output
Impedance 5Ω
Maximum Output Level
+6.5dBu
@ 0dBFS
8.5mW into 270Ω
Maximum Power (mW)
28mW into 33Ω
THD+N -96dB unloaded
Frequency Response 20Hz - 20KHz, ±0.5dB
Camera Output
Impedance 220Ω
Maximum Output Level -24.5dBu
THD+N
(Max Output, -1dBFS, -73dB
22Hz - 22kHz)
Frequency Response 20Hz - 20KHz ±0.2dB
29
