Example Of Loopback Usage; Recording Tracks Into Software - Focusrite Audio Engineering vocaster one studio User Manual

VOCASTER HUB SOFTWARE

Example of Loopback usage

You might want to use both Loopback inputs
when you're recording a show but need
independent recordings of other software
sounds to mix later. For example, in your
show, you want to record your conversation
with a guest in a video call in addition to
including a sound or jingle playback from
another audio playback software.
Your video call software (e.g., Zoom), routes
its output to Playback 1-2 by default. This
appears as Loopback 1 in the mixer. You
can then route the output of your playback
software to Playback 3-4, which becomes
available as Loopback 2.
In your recording software you can now have
separate tracks for recording:
• Loopback 1 appears on your DAW
channels 7 and 8
• Loopback 2 appears on your DAW
channels 9 and 10
For all further details, please refer to
the Vocaster Hub User Guide.
focusrite.com

Recording Tracks into Software

Depending on which recording software you
use, you can pick from up to ten channels to
record from, to separate tracks.
The ten channels you'll see are:
DAW Input Number Vocaster Input
1
Video Call L
Video Call R
2
3
Show Mix L
Show Mix R
4
5 Host Microphone
6 Aux
7
Loopback 1 L
Loopback 1 R
8
9
Loopback 2 L
Loopback 2 R
10
Tell the world
Use
A mix of all inputs excluding Loopback, this is a mix-minus so a video call
guest can hear your whole show without hearing (minus) themselves.
A stereo mix of all the inputs to record your whole show.
The Host microphone input.
A mono feed from a device connected to the phone input on Vocaster.
Signal from software fed from software playback 1-2.
Signal from software fed from software playback 3-4.
