2.1 How to connect your modem on an
ADSL/VDSL connection
5
Set up your Spark
modem on ADSL/VDSL
Things you'll need from the box
Power supply
unit
OR
ADSL Phone
cable/VDSL cable
If you have a standard
jackpoint (BT) only
Plug the modem into a power
A.
supply.
Connect the
B.
from the modem's DSL port to
the filter's ADSL port.
Connect the filter to the
C.
jackpoint.
Filter
(ADSL only)
cable
GREY
