FEATURES
Microprocessor based controller
♦
16 detector zones
♦
Maximum 25 detectors in each zone
♦
Day / night mode
♦
Short / open circuit detection
♦
Compact size
♦
Easy programming
♦
DESCRIPTION
GST116 Conventional Fire Alarm Control Panel is a microprocessor based multi-zone fire alarm
control panel which is fully complied with European Standard EN54-2. The configuration of the
system is programmable and saved in non-volatile memory that will remain the program on the
panel even when the panel lost both the main power and battery power.
The panel has 16 detector zones. Each zone can be connected with up to 25 GST smoke or heat
detectors while using end of line resistor; or 15 smoke detectors or heat detectors with the active
end of line unit. The manual call points can be wired in the same detector zone with the smoke
detectors or heat detectors. The number of the manual call points is unlimited.
SPECIFICATION
Number of detector zone
Number of sounder output
Power supply
Operating temperature
Detector loop voltage
Max. number of detectors per
loop with end of line resistor
Max. number of detectors per
loop with active end of line unit
Detector impedance
for fire alarming
End line resister of
detector loop
Sounder output voltage
Max. output current
End line resister of sounder
output
Auxiliary power output
Standby battery
Dimension
CONVENTIONAL FIRE ALARM PANEL
The panel has five supervisory outputs and one
non-supervisory output. They are four supervi-
sory sounders and one supervisory alarm output
16
and one non-supervisory fault output (N.O. and
4
N.C. contact).
187~242Vac
0°C to 40°C
The panel has functions of alarm indication,
±4Vdc
24
fault indication, testing mode and isolation
mode, Day / Night Mode selection.
25
The operation of the panel is simple. All control
15
functions and programming are made by the
150Ω ~ 1.5kΩ
keypad and switches on the panel or the
(normally 470Ω)
switches and jumpers on the circuit board. No
4.7kΩ
other programming tools are required.
±4Vdc
keys are provided to ensure secured operation
24
1A
of the control panel.
4.7kΩ
This model provides a simple and low-cost
solution to protect a small space from fire
24Vdc, 0.5A
such as houses, shops, hotels, schools and
7Ah
factories.
380 x 320 x 95mm
GST116
GST116
Two
