WHITECROFT LIGHTING Florin E3 Series Installation Leaflet

TECHNICAL SUPPORT
Telephone: 0161 331 5700
E-mail: technical@whitecroftlight.com
http://www.whitecroftlighting.com
WARNING: TO AVOID INJURY, KEEP
FINGERS CLEAR OF SPRINGS WHEN
REMOVING RECESSED LUMINAIRE
FROM CEILING
Specification – FLS31EP/65,
FLS32EP/65,
FLSH31EP/65
Supply Voltage: 230Vac ± 10% 50/60 Hz
Supply Current: 20mA @ 230V ac
Ambient Temperature: 0°C to +35°C
Conductor size: 0.5 – 2.5mm²
Mounting Screws: M4
Weight of Luminaire: 250g (incl. battery)
IP Rating of Luminaire: IP65
Average Lumen output: 260lm
Battery: 6.4V, 1.5Ah 2 x 18650
cells
LiFePO
4
Specification – FLS31/CB/65,
FLS32/CB/65,
FLSH31/CB/65
Central Supply Voltage: 93-265V dc/ac
50/60Hz
Central Supply Current: 20mA @ 230V ac
Central supply output current: 670mA
Ambient Temperature: 0°C to +35°C
Conductor size: 0.5 – 2.5mm²
Weight of Luminaire: 65g
IP Rating of Luminaire: IP65
Average output (Lumens) 260 lm
For Photometry refer to
www.whitecroftlighting.com
Please note: All images shown are for illustration purposes and should be used only for reference.
GENERAL INFORMATION
1) A qualified electrician, in accordance with IEE
wiring regulations, should carry out connection to
mains wiring.
2) Ensure that the rated voltage and frequency
requirements are compatible with the available
mains supply.
3) Cleaning of reflectors and lenses should be
carried out using clean, soft and lint free cloths
and anti-static cleaning fluid
4) Do not carry out high voltage insulation test, i.e.
500/1000v this may damage internal components.
SAFETY INFORMATION
The luminaire should be positioned so that
prolonged staring into the luminaire at a distance
closer than 0.24m is not expected.
Florin IP65
Installation Leaflet
Whitecroft Lighting Limited
Burlington Street, Ashton-under-Lyne, Lancashire OL7 0AX
Telephone +44 (0)161 330 6811 Facsimile: +44 (0)161 331 5855
Registered No. 3848973 England Registered Office: As above
Dec 2021 - Rev B
