WHITECROFT LIGHTING Foil SRD Installation Leaflet

SPECIFICATION

Lumen packages: 4800lm/6000lm/7200lm
Finishes: Body Silver RAL 9006 30% gloss polyester powder-coat
White RAL 9003 30% gloss polyester powder-coat
Geartray White Reflective gloss polyester powder-coat
Materials: Main body - 0.9mm micro perforated mild steel
Canopy/Gear Tray - 0.7mm mild steel.
Diffuser - Extruded polycarbonate
Acoustic absorbers - 80Kg/m
Control Gear: Fixed Output/DALI control gear as specified
Operating Temp: 25°C
Supply: 220-240v 50/60hz AC
Connection: Unfused 2.5mm terminal block (10mm wire strip length)
IP Rating: IP20

GENERAL INFORMATION

1. A qualified electrician, in accordance with IEE wiring regulations, should carry out
connection to mains wiring.
2. Ensure that the rated voltage and frequency requirements are compatible with the
available mains supply.
3. Cleaning of reflectors and lenses should be carried out using clean, soft and lint free
cloths and anti-static cleaning fluid.
4. Do not carry out high voltage insulation test, i.e. 500/1000v this may damage internal
components.
5. Electrically isolate this luminaire during maintenance.
6. Replacing the light source within this luminaire shall only be carried out by the
manufacturer, service agent or a similar qualified person.
TECHNICAL SUPPORT
Tel: 0161 331 5700
e-mail: technical@whitecroftlight.com
www.whitecroftlighting.com
3
Tissue wrapped compressed fibreglass
Foil SRD
Installation Leaflet
PK-LEAF-FOILSRD
Whitecroft Lighting Limited
Burlington Street, Ashton-under-Lyne, Lancashire OL7 0AX
Telephone +44 (0)870 5 087 087
Registered No. 3848973 England
May 2018 - Rev2 June 2016 - Rev1
Facsimile: +44 (0)870 5 084 210
As above
