PRODUCT DATA
Aerial Industry is a high output, high efficiency high bay luminaire for general
applications.
The luminaire is constructed from sheet steel, polycarbonate and acrylic materials.
Aerial Industry incorporates the latest high efficiency LED light engines and drivers for
optimum efficiency and luminaire life.
The luminaire range includes a Quadraprism, Opal diffuser, and High Rack optic to suit
most applications.
Aerial Industry can be wire suspended or surface / trunking / drop rod mounted by
utilizing one of the optional suspension kits available.
The luminaire is supplied complete with external plug and socket cable terminations for
speed and ease of wiring.
PRODUCT SPECIFICATION
Finish:
Body
Materials:
Body Assembly
Rear Backplate
Diffuser Options
End cap
Control Gear:
DALI addressable or Fixed output LED Drivers.
Emergency:
3 hr integral emergency pack (Refer to website for options)
4000k high output LED's
Light Source:
Op. Temp:
0 - 35 °C (Model dependant, please refer to website)
Power:
Please refer to website for latest Wattage
IP Rating:
IP40 front & rear
Connection:
Plug & Socket - 2.5mm
Suspension:
Wire / Trunking / Surface / Drop Rod
TECHNICAL SUPPORT
Telephone: 0161 331 5700
Supply:
240V AC, 50Hz
E-mail:
technical@whitecroftlight.com
http://www.whitecroftlighting.com
Connection:
1.5mm SQ Panel mount plug & sockets on rear face
- White high reflective paint
- Sheet Metal
- 0.9mm mild steel
- 2.5mm Quad Prism Acrylic
- 2mm Opal Satine Acrylic
- 15 degree lens with clear diffuser.
- Injection moulded white Polycarbonate.
2
maximum cable
Aerial Industry
HIGH BAY LUMINAIRE
INSTALLATION INSTRUCTIONS
PK/LEAFAERIND
Whitecroft Lighting Limited
Burlington Street, Ashton-under-Lyne, Lancashire OL7 0AX
Telephone +44 (0)161 330 6811
Registered No. 3848973 England
OCTOBER 2018 - Rev C
Facsimile: +44 (0)161 331 5855
As above
Registered Office:
