1.Fasten four hook racks with eight screws(M4*6) (Picture 1).
2.Keep enough distance between the heater, floor and wall (Picture 2).
3.Use the drill dimension paper to drill the top two holes (Φ8) into the wall. Put the plastic
expansion tube into the holes, then fasten the expansion screws (ST4*40) in the holes
(Picture 3).
4.Hang the top two hook racks on the screws (ST4*40) (Picture 4). Mark the position for the
two bottom hook racks on the wall. Remove the heater and drill two bottom holes (Φ8)
into the wall, then put the plastic expansion tube into the holes (Picture 4).
5.Hang the heater on the wall and put the expansion screws (ST4*40) into the bottom two
holes (Picture 5).
Freestanding
1 – Place the feet onto the bottom of the body.
2 – Fasten the feet with four screws (ST4*35).
CAUTION: Before starting the appliance, make sure it's wall mounted correctly. If it's not
parallel to the floor, technical problems can occur.
Control panel and LCD screen
①Heating,
②Power
③Temperature
④Open window function
Control panel, LCD screen and remote control
On/Off
Power setting
Week timer
Temperature setting
Remote include a CR2025 cell button. The function is same with control panel, remove the
Insulating sheet before using.
INSTRUCTIONS FOR USE
Mode setting
Increase
Decrease
Ion
25
⑤Comfort
⑥ECO
⑦Ion
⑧Week timer
