- Page 1 Station Bed D E S I G N E D I N 2 0 1 3 A S S E M B LY N O T E S | R E V 0 0...
- Page 2 Parts & Hardware Pt. 1080 Pt. 1079 Pt. 3005 Pt. 3006 Pt. 9004 Pt. 9001 Center foot Bed slats Left side rail Right side rail Center rail End rails Headboard rail Headboard *King bed ships with x7 Pt.1079 1 | 8 4 4 . 4 2 5 . 8 3 6 8 S T A T I O N B E D...
- Page 3 Step 01 A S S E M B L E R A I L S . Loosely attach the side rails to the end rails. Be sure to note the position of the front and Back end back end rails. rail has extra bolt holes...
- Page 4 Step 02 AT TA C H H E A D B O A R D S U P P O R T. Attach the headboard support rail to the frame. Tighten all hardware. P t . 1 0 8 0 x 6 P t .
- Page 5 Step 03 A S S E M B L E T H E C E N T E R R A I L . Attach the center foot to the center rail as shown. P T. 1 0 79 x 2 PT.
- Page 6 Step 04 I N S TA L L C E N T E R R A I L . Attach the center rail by setting it into the center rail brackets. 5 | 8 4 4 . 4 2 5 . 8 3 6 8 S T A T I O N B E D...
- Page 7 Step 05 AT TA C H T H E H E A D B O A R D. *The king size headboards have an additional attachment point and hardware. P T. 1 0 7 9 X 4 * Additional Attachment point for king beds P T.
- Page 8 Step 06 I N S TA L L T H E B E D S L AT S . Starting from the foot of the bed, align the first slat in between the rail and metal notch. Stretch slats toward the headboard and place the last slat between the metal notch and headboard.
