WHAT YOU’LL NEED Drill / Impact Driver x2 Socket Set & Shifter Ladder x2 Mallet Forklift / Crane / Scissor Lift * Tape Measure Stringline Level Marking Pencil Stanley Knife Warning read instructions carefully before use. Recommended procedure to follow in this document. For safety reasons it is recommended that at least four persons set up any Crest Marquee.
CREST MARQUEE OVERVIEW 2. Structure Description 1. Introduction The Extreme Marquees Crest main structure is made up of extruded aluminium and steel. The adjustable frame Base Plate is able to be used on any ground surface. Frame Specifications Max Allowed Windspeed: 80km/hr 0.3kn/m2...
3. Part Description Item # Description Item # Description Ridge Connector M10 x 70 Bolt A - Reinforcing Beam Roof Beam M10 x 100 Bolt Corner Connector M10 x 120 Bolt + Nut (Type A / B) Corner Upright Washer Base Plate M16 x 30 Bolt (Type A / B)
4. Assembly Cautions 4.1 Dismantle Cautions Before commencing construction refer to the Ground Set Out Mark and pack all components in appropriate product covers. plan of the marquee. Measure the ground area and confirm the marquee dimensions. Ensure Roof and Walls Fabrics are completely dry before packing down and fitting the protective covers.
Page 8
5. Construction When commencing construction of the Crest Marquee build Refer to the Elevation Drawing and Parts List to confirm your each frame bay section flat on the ground. method of construction for Step 2. FRAME TYPE A FRAME TYPE B STEP 1: Assemble Base Plate and Corner Upright STEP 2 (A):...
Page 9
Refer to the Elevation Drawing and Parts List to confirm your method of construction for Step 5. STEP 5 A: Connect the Reinforcing Beam Connect the two bays together using the Frame Reinforcing Beam and bolt together. Ridge Connector with Roof beams Ridge Connector STEP 3: Assemble Ridge Connector with Roof Beams...
Page 10
Refer to the Elevation Drawing and Parts List to confirm your method of construction for Step 6. Roof Purlin Gable Support with gable base plate Gable support top view Eave Purlin STEP 6: Gable Eave Rail Assemble Eave Purlin and Roof Purlin Gable Support Insert the end of Eave Purlin into the ‘D’...
Page 11
STEP 8: Ground Fixings The frame must be fixed and secure prior to installing the Roof and Wall Fabric. Ensure you have the correct ground fixings for your application. Pin Puller Grass: Steel Stakes Fix each Base Plate with Steel Stakes. Ensure stakes are appropriately secured into the soft surface (Grass/Dirt).
Page 12
INSTALLATION HINTS & TIPS Installation of Roof Fabric View of the ‘outside’ and ‘underside’ of Roof Panels. Outside of Roof Panels Underside of Roof Panels REFER TO STEP 9 ON NEXT PAGES www.extrememarquees.com.au 1300 850 832...
Page 13
INSTALLATION HINTS & TIPS Installation of Roof Fabric When connecting the Ropes to the Webbing on Roof Panel DO NOT tie a knot use the following loop technique. This technique avoids the knot getting wedged of Roof Purlins. 1. Fold the rope. 2.
Page 14
STEP 9: Installation of Roof Fabric Image 2 Put the two installation ropes on the top of the frame as image 1 & 2. Layout the roof cover on ground as image 2 To keep the roof cover clean, pls put one fabric or carpet or pallet on the bottom to hold the roof.
Page 15
Tie the installation ropes around the webbing of the roof cover. Insert the left/right kedar side of roof cover into channel of roof beam. IMPORTANT The webbing and tied off rope MUST be on the Four people are required to completed this process. underside of the roof panel.
Page 16
Continue to thread the roof kedar into the channel of the roof beam Insert the curve tension bar into bottom sleeve of roof cover. until the roof is fitted. The bar is to be inserted the ‘smiley’ way up. www.extrememarquees.com.au 1300 850 832...
Page 17
STEP 10: Installing the Gable Fabric 10.1 Un-zip/separate the gable into two pieces left/ right. 10.3 Zip the centre of the left/right gable cover together 10.4 Insert the curve tension bar into bottom sleeve of the gable cover. 10.2 IMPORTANT : Curve tension bar must be put into the sleeve in ‘smiley’ Insert the left/right side of gable cover kedar into the channel of roof way up.
Page 18
STEP 11: Installing the Side Wall Fabric 10.5 Install one connecting tube to connect the two curve tension bars and use fastener to tension gable cover. NOTE: Inside view of wall 11.1 Un-zip/separate the wall into two pieces left/right IMPORTANT The sleeve at the bottom of the wall panel is to be on the inside of marquee.
Page 19
11.2 Insert/slide the wall kedar into channel of eave purlin Tip: gable & side wall use the same installation method www.extrememarquees.com.au 1300 850 832...
Page 20
11.4 Zip the centre of the left/right side walls together. 11.3 Insert the left/right kedar of the side wall into the channel of uprights. Slide the wall kedar from top to bottom of the side uprights. www.extrememarquees.com.au 1300 850 832...
Page 21
Image 1 Image 2 Image 3 11.5 Insert the wall bar into the bottom sleeve of the wall, using bolts tension the wall to the frame. Tips: Gable end wall bar/s, refer to image 1 and 2. Side panels wall bar/s, refer to image 3. www.extrememarquees.com.au 1300 850 832...
Page 22
PLEASE NOTE: The tension work can only be completed once the roof, gable, and side walls have been installed. 12.2 STEP 12 Internal bay roof tension system Fix Thread Bracing and Tension Install one connecting tube to connect the two curve tension bars. Using a eave screw to tension the two roof panels together.
Page 23
Product Cautions and Safety When the marquee is in use, do not leave your marquee unattended. Wind rating as per engineering certificate, review weather conditions. When the Marquee is in use and if part of the structure looks damaged or not fit for purpose the marquee should be dismantled at once for safety reasons.
