BEFORE YOU BEGIN
ATTENTION: Read instructions
carefully before use.
Recommended setup procedures are
outlined in this document.
For safety reasons it is recommended
that at least two persons erect any
marquee setup.
Ensure the area is free from any sharp
objects, overhead structures or other
obstructions.
WARNING: Keep clear of
overhead power lines.
SIZES: 5x5m, 6x6m
CONTENTS
TRANSPORTING
SECURING YOUR MARQUEE
THINGS YOU SHOULD KNOW
Your marquee is supplied with steel pins and
tie-down ropes. These MUST all be used. For
setup on hard surfaces such as pavement,
weight plates, water weights or sandbags
MUST be used for security.
These are add-on accessories that can be
purchased separately.
All roof tie-down straps MUST be attached
and tensioned. These security methods
will maximise safety. However, due to the
unpredictable nature of weather, damage
prevention is not guaranteed.
All folding marquees are considered temporary
structures and MUST be packed down and
stowed away in any adverse weather conditions
such as storm, rain or wind gusts. Your marquee
should never be left up unattended.
Prolonged exposure to the sun can seriously
degrade the material and/or cause it to
become discoloured.
1
6X6M SETUP INSTRUCTIONS
1
1
1
1
2
3
INSTRUCTIONS & CARE
WARNING: KEEP ALL FLAME
AND HEAT SOURCES AWAY
FROM THE TENT FABRIC.
This marquee is built with flame
retardant. The fabric may burn if left
in continuous contact with any flame
source. The application of any foreign
substance to the marquee fabric may
render the flame-resistant properties
ineffective.
THIS PRODUCT MEETS AUSTRALIAN
STANDARDS
Please check with your local
regulations prior to purchasing this
item. Some municipalities have
restrictions and requirements.
4
5
5
6-9
10
