NordicTrack R35 User Manual

Hide thumbs Also See for R35:

Advertisement

Table of Contents

nordictrack.com
Model No. NTEX14921.0
Serial No.
Write the serial number in the space
above for reference.
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today,
go to my.nordictrack.com.
CUSTOMER CARE
For service at any time, go to
support.nordictrack.com.
Or call 1-800-TO-BE-FIT
(1-800-862-3348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
Serial
Number
Decal
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R35 and is the answer not in the manual?

Questions and answers

Tom Meyers
February 17, 2025

Just purchased the Nordic R35 Recumbent Bike. Accidentally knocked the plug with multiple prongs loose and broke some prongs from Part #10 on the diagram Seat Handlebar / Wire Assembly. Can just the pronged plug be purchased and can it be replaced without buying the whole assembly. I know that I can use the console to adjust settings. Just wanted to know if there is a heap quick fix. Thanks

0
1 comments:
Mr. Anderson
May 14, 2025

Based on the provided context, if a replacement power adapter (pronged plug) is needed, it can be obtained separately by calling the telephone number on the cover of the manual. There is no information stating that the whole Seat Handlebar / Wire Assembly must be purchased to replace the power adapter.

This answer is automatically generated

0
Susan
February 13, 2025

pedals sticking brand new bike

0
1 comments:
Mr. Anderson
May 14, 2025

The pedals on the NordicTrack R35 bike are sticking because the magnetic resistance system is improperly set. Even at the lowest manual setting, the pedals are very difficult to turn, suggesting that the tension needs to be reset or adjusted.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for NordicTrack R35

Summary of Contents for NordicTrack R35

  • Page 1 Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to my.nordictrack.com. CUSTOMER CARE For service at any time, go to support.nordictrack.com. Or call 1-800-TO-BE-FIT (1-800-862-3348) Mon.–Fri. 6 a.m.–6 p.m. MT Sat. 8 a.m.–12 p.m. MT Please do not contact the store.

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. NORDICTRACK and IFIT are registered trademarks of ICON Health & Fitness, Inc. The Bluetooth ® word mark and logos are registered trademarks of Bluetooth SIG, Inc. and are used under license. Google Maps is a trade- mark of Google LLC.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
