Summary of Contents for Motorline professional CORTINA ZIP
- Page 1 CORTINA ZIP CORTINA ZIP USER’S AND INSTALLER’S MANUAL v1.0 REV. 06/2022...
-
Page 2: Table Of Contents
00. CONTENT 01. SAFETY INSTRUCTIONS INDEX ATTENTION: 01. SAFETY INSTRUCTIONS This product is certified in accordance with European Community (EC) safety standards. 02. AUTOMATION This product complies with Directive 2011/65/EU of the TECHNICAL CHARACTERISTICS European Parliament and of the Council, of 8 June 2011, on KIT COMPOSITION the restriction of the use of certain hazardous substances DIMENSIONS... - Page 3 01. SAFETY INSTRUCTIONS 01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. very important. Read all instructions carefully before beginning the WARNINGS FOR TECHNICIANS installation/usage procedures and keep this manual in a safe place that it can be consulted whenever necessary.
- Page 4 01. SAFETY INSTRUCTIONS 01. SAFETY INSTRUCTIONS RESPONSABILITY September 2009. • Attach the permanent label for the manual release as close as possible • Supplier disclaims any liability if: to the release mechanism. • Product failure or deformation result from improper installation •...
-
Page 5: Automation
• Adherence 45/45 daN • Operating temperature -30°C to 70°C If you want to install a climate sensor, the CORTINA ZIP must be ordered with a TUB90M8 MT • Bottom beam motor and an MC65 electronic control board. • User manual... -
Page 6: Dimensions
02. AUTOMATION DIMENSIONS • CORTINA ZIP WITH SAFE PROFILE (Inside the passageway) • CORTINA ZIP WITHOUT SAFE PROFILE (Outside the passageway) Dimensions shown in mm. Dimensions shown in mm. Max. 4000 Max. 4090 Máx. 3910 Max. 4000 Max. Max. 3000... -
Page 7: Installation
03. INSTALLATION FIXATION OF THE SAFE PROFILE REMOVE THE MOTOR Remove the front cover of the safe profile to access the interior: A ⋅ Loosen the cover screws; B ⋅ Open the cover and remove it. TOP FIXATION BRISA SOLAR FIXATION LATERAL FIXATION In the case of installation There are 3... -
Page 8: Fixation Of The Lateral Guides And Tarpaulin
03. INSTALLATION FIXATION OF THE LATERAL GUIDES AND TARPAULIN Each lateral guide is made up of five parts: Part A • 1 base Part B • 2 side covers Part C • 1 inner guide for the tarpaulin Part D • 1 plastic cover DISASSEMBLY GUIDES Press the parts B in the indicated area to release them from the lateral guides. -
Page 9: Fixation Of The Safe Profile Cover
Adjustment A Adjustment B Adjustment B Adjustment A WINDING In the case of CORTINA ZIP, the tarpaulin winding is done from the inside: • Adjustment A - Opening FIT THE COVER • Adjustment B - Closure Fit the cover into the top slot on the safe profile.
