EN
BRISA SOLAR
BRISA SOLAR
USER'S AND INSTALLER'S MANUAL
v1.2
REV. 07/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BRISA SOLAR and is the answer not in the manual?

Questions and answers

Related Manuals for Motorline professional BRISA SOLAR

Summary of Contents for Motorline professional BRISA SOLAR

  • Page 1 BRISA SOLAR BRISA SOLAR USER’S AND INSTALLER’S MANUAL v1.2 REV. 07/2019...

  • Page 2: Table Of Contents

    01. SAFETY INSTRUCTIONS Community (EC) safety standards. 02. AWNING This product complies with Directive 2011/65/EU of the BRISA SOLAR European Parliament and of the Council, of 8 June 2011, on TECHNICAL CHARACTERISTICS the restriction of the use of certain hazardous substances in ORIENTATION AND CONSTRUCTION electrical and electronic equipment.

  • Page 3: Safety Instructions

    01. SAFETY INSTRUCTIONS GENERAL WARNINGS motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. very WARNINGS FOR TECHNICIANS important. Read all instructions carefully before beginning the installation/ usage procedures and keep this manual in a safe place that it can be •...
  • Page 4 01. SAFETY INSTRUCTIONS RESPONSABILITY • Attach the permanent label for the manual release as close as possible to the release mechanism. • Supplier disclaims any liability if: • Disconnect means, such as a switch or circuit breaker on the electrical •...

  • Page 5: Awning

    BRISA SOLAR BRISA SOLAR The BRISA SOLAR awning is constructed entirely of aluminum, which makes it ideal for covering exterior On the awning you will find the following components: spaces. Solutions for esplanades, terraces or winter gardens. The electrically controlled blades allow light through them, air renewal from the surrounding space or the full water inlet seal.

  • Page 6: Orientation And Construction

    ORIENTATION AND CONSTRUCTION When the width, projection or area are greater than the maximums defined, you can group several The BRISA SOLAR is an awning for protection modules in both width and projection to form a larger awning. of exterior areas with integral aluminum construction.

  • Page 7: Installation

    03. INSTALLATION FIXING BETWEEN WALLS - DIRECT FIXATION MARKING ON THE WALL APPLICATION PROFILES Mark the holes in the front and rear profiles (see detail A). DETAIL A 90º BORINGS IN WALL APPLICATION PROFILES Drill the markings along the profiles with Ø10mm (2A).

  • Page 8: Wall And Leg Fixing

    03. INSTALLATION WALL AND LEG FIXING MARKING ON THE WALL APPLICATION PROFILE Mark the holes in the profile to be installed on the wall (see detail A on page 6A). BORINGS IN WALL APPLICATION PROFILES Drill the markings along the profiles with Ø10mm (2A).

  • Page 9: Legs Fixing

    03. INSTALLATION LEGS FIXING ASSEMBLY OF THE FRAME Place all profiles of the frame on the floor, aligned in the correct position for assembly. FIT OF THE PROFILES Apply the silicone seal to the diagonal faces of the various profiles. 90º...

  • Page 10: Assembly The Blades

    03. INSTALLATION ASSEMBLY THE BLADES FIXING BLADES Fit all the blades into the supports mounted on the side profiles of the frame.   Put the blade upright. Fit the rotating axes of the plastic tops of the blades into the existing frame supports, Turn the blade to the horizontal position.

  • Page 11: Motor Assembly

    03. INSTALLATION MOTOR ASSEMBLY FIX MOTOR PROFILE Attach the motor base profile to the side profiles of the frame with self- tapping screws. Do not tighten the screws as far as possible to avoid crushing the rubber. FIXING MOTOR SQUARE NUT Make sure that the distance of the block and motor support is correct (see detail A).

  • Page 12: Assembly Led Lighting Kit

    03. INSTALLATION 03. INSTALLATION ASSEMBLY LED LIGHTING KIT ASSEMBLY MOTOR COVER ATTACH PROFILE FIX THE LED LIGHTING TAPE Fit the motor cover profile into the rotational zone of the motor Unwind the LED lighting strip and install it on the framing frieze base section.

  • Page 13: Regulation

    04. REGULATION LIMIT SWITCHES Turn the desired tuner by only half a turn (180 °) in the direction corresponding to the desired setting (see detail A). Test the motor behavior. Adjust and test this way until you reach the desired opening and closing points.

  • Page 14: Maintenance

    05. MAINTENANCE INSTRUCTIONS FOR WATER DRAINAGE It is important create drainage points in the BRISA SOLAR to avoid accumulation of water inside the frame. Follow the instructions and recommendations below: CHOICE OF SITE (WHEN NO PRIOR HOLES EXIST) Mark the site where you want to place the drainage hole (Ø50mm), taking into account the dimensions 39mm indicated for the option you want (OPTION A / OPTION B).

  • Page 15: Troubleshooting

    06. TROUBLESHOOTING FINAL CONSUMERS AND SPECIALIZED TECHNICIANS INSTRUCTIONS Problems Behavior Procedure The awning is not secure • Check the installation measures. • The screws are not suitable for the wall structure. properly on the wall. • Check that the number of screws is sufficient and that they are indicated in this manual. The awning does not remain •...
