Intellinet 523233 User Manual

802.11b wireless router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
802.11b Wireless Router
User Manual
FCC Certifications
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. The equipment version marketed in US is restricted to usage of the channels 1-11
only. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End
users must follow the specific operating instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
The equipment version marketed in US is restricted to usage of the channels 1-11 only
CE Mark Warning
This equipment complies with the requirements relating to electromagnetic compatibility, EN55022 class B for
ITE, the essential protection requirement of Council Directive 89/336/EEC on the approximation of the laws of
the Member States relating to electromagnetic compatibility.
Company has an on-going policy of upgrading its products and it may be possible that information in this
document is not up-to-date. Please check with your local distributors for the latest information. No part of this
document can be copied or reproduced in any form without written consent from the company.
Trademarks:
All trade names and trademarks are the properties of their respective companies.
Copyright © 2003, All Rights Reserved.
Document Version: 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 523233 and is the answer not in the manual?

Questions and answers

Related Manuals for Intellinet 523233

Summary of Contents for Intellinet 523233

  • Page 1 802.11b Wireless Router User Manual FCC Certifications This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. The equipment version marketed in US is restricted to usage of the channels 1-11 only.

  • Page 2: Table Of Contents

    Product Specifications ··········································································· Appendix ································································································· Unpacking Information Thank you for purchasing the Wireless Router. Before you start, please check all the contents of this package. The product package should include the following: 1. One Wireless Router 2. One power adapter 3.

  • Page 3: Introduction To Wireless Router

    General Description The Wireless Router built-in with 4-port 10/100Mbps Fast Ethernet Switch is the latest generation of Wireless router product for Home/Office and SOHO users who are thirsting high speed Internet access. This full-feature and self-contained compact Wireless Router will be fully for broadband access in both of LAN and Wireless environment.

  • Page 4: The Front Panel

    To reboot the Router, Press the button for 2-5 seconds and then release it, and all the setting won’t be erased. Wait for the Router to complete the reboot, and then you can start to use it.

  • Page 5: The Rear Panel

    There are three ways to place the Router. The first way is to place the Router horizontally on a surface. The second way is to attach the router to the wall. The third way is to stand the Router vertically on a surface. These options are explained in further detail below.

  • Page 6: Installing And Using Wireless Router

    Ethernet cable from the computer’s Ethernet card to an 10/100Mbps Ethernet port on the back of the Wireless Router. Plug-in the power adapter to the Router and the other side to the wall outlet. Computer configuration setup In order to communicate with Wireless Router, the connected computer needs to install the TCP/IP protocol and setup the related address information.
  • Page 7 Double click the “Network” icon on the Control Panel window Click the “Configuration” tab and check the TCP/IP protocol is available or not. If yes, skip the procedures 5 ~ 6. If no, click the “Add” button. Select “Protocol” item on the Select Network Component Type window. After that, click “Add”...
  • Page 8 Fixed: If there are some clients who need to get fixed IP addresses for some reasons and the nodes also need to access Internet through the Wireless Router then the following steps used to configure system Select “Specify an IP address” in the IP Address Tab of the TCP/IP Properties window and enter 192.168.1.*** in the IP Address field (the *** is a...

  • Page 9: Wireless Router Configuration Setup

    Don’t forget to change the Username and Password in configuration’s Authentication to ensure the security. Status In the home page of the Wireless Router, the left navigation bar shows the options to configure the system. In the right navigation screen is the summary of system status for viewing the configurations.

  • Page 10: Wireless

    Associate Clients Number of all active wireless stations that are connecting to the access point. BSSID Basic Service Set Identification of AP LAN Configuration IP Address IP Address of Router Subnet Mask Subnet Mask DHCP Server Enabled or Disable of DHCP MAC Address MAC Address of LAN-port...
  • Page 11 Click <Apply> at the bottom of the screen to save the above configurations. You can now configure other advance sections or start using the router (with the advance settings in place) Active Wireless Client Table MAC Address MAC address of this active wireless station.
  • Page 12 If the packet size is smaller the RTS threshold, the wireless router will not send this packet by using the Threshold RTS/CTS mechanism. Beacon The period of time how long a beacon is Interval broadcasted. The "Data Rate" is the data packets limitation this wireless router can transmit.
  • Page 13 APs wirelessly. To make it work, you must ensure that these APs and the Router are in the same Channel and add these APs MAC Address and Comment values into the WDS list. Don’t Forget to Enable the WDS by click the check box of “Enable WDS”...

  • Page 14: Tcp/Ip Setting

    TCP/IP Setting LAN Interface Setup To set up the configuration of LAN interface, Private IP of you router LAN Port and Subnet mask for your LAN segment. Configuration IP address The IP of your Router LAN port (Default 192.168.1.1) Subnet Mask Subnet Mask of you LAN (Default 255.255.255.0) 802.1d...
  • Page 15 NIC, but instead changes the MAC address reported by Wireless Router to client requests. To Change the MAC address, enter it in the text box. Enable To Enable the user to access this Router through Internet, Enter the specific IP and the port number Access...

  • Page 16: Firewall Configuration

    The firewall could not only obstruct outside intruders from intruding your system, but also restricting the LAN users. Port Filtering To restrict certain type of data packets from your LAN to Internet through the Router, add them on the Current Filtering Table. Configuration STEPS Click the check box of “Enable Port Filtering”...
  • Page 17 IP filtering The Wireless Router could filter the outgoing packets for security or management consideration. You can set up the filter against the IP addresses to block specific internal users from accessing the Internet. Configuration STEPS Click the check box of “Enable IP Filtering” to enable the function.

  • Page 18: Syslog

    Port forwarding The Port Forwarding allows you to re-direct a particular range of service port numbers (from the Internet/WAN Ports) to a particular LAN IP address. It helps you to host some servers behind the router NAT firewall. Configuration STEPS Click the check box of “Enable port forwarding”...

  • Page 19: Statistics

    Click Upload to start the upgrade process. Please don’t close the WEB-browser and wait for process to complete. When Upgrade is completed, you can start to use the router. Save and Reload To save setting to file, click “Save...” button.

  • Page 20: Product Specifications

    Product Specifications IEEE802.3, 10BASE-T IEEE802.3u, 100BASE-TX Standard IEEE802.3x full duplex operation and flow control IEEE802.11b wireless LAN infrastructure 1 * WAN port Interface 4 * 10/100 RJ-45 Fast Ethernet switching ports One wireless LAN comply with IEEE 802.11b WAN Connection Ethernet 10/100 Mbps RJ-45 (10BASE-T): Category 3,4,5 UTP Cable Connections RJ-45 (100BASE-TX): Category 5 UTP...
