sensolus TRACK 1020 Battery Replacement Manual

TRACK 1020 Battery replacement manual
Step 1
• Turn the tracker face down.
• Unscrew the 6 screws.
Tip: If using a power drill, use power setting 7, on low. (Note:
not all power drills have the same settings!)
Step 4
Turn around the circuit board and battery pack
Step 7
Reinsert the circuit board and battery pack.
Make sure the LED is facing downward and the foam on
the battery is facing upwards.
www.sensolus.com | info@sensolus.com
Step 2
Remove the back plate and the 6 screws.
Step 5
Remove the battery pack - pull them out of the
connector.
Step 8
Close the case again by tightening the 6 screws in the
corresponding holes. Be careful not to break the casing
when using a power drill.
Step 3
Remove the circuit board and the battery pack.
Step 6
Add a new battery pack, be carefull with the connector.
A green LED will blink when the battery pack is
connected.
