Summary of Contents for InFocus Learn Big XS1
-
Page 1: Reference Guide
Reference Guide... -
Page 2: Table Of Contents
Operating in a high altitude environment ... 40 Adjusting the sound ... 41 Personalizing the projector menu display... 41 Shutting down the projector ... 42 Menu operation... 43 Maintenance ...50 Care of the projector ... 50 Lamp information ... 51 Troubleshooting ...57... -
Page 3: Introduction
Detachable keypad on the projector to prevent stealing • Splash Screen lock to prevent unauthorized use • Selectable quick cooling function makes the projector cool in a shorter time • Presentation timer for a better control of time during presentations •... -
Page 4: Shipping Contents
Shipping contents The projector is shipped with the cables required for connection to a PC or video equipment. Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. -
Page 5: Projector Exterior View
Projector exterior view Front/upper side Rear/lower side 14 15 19 20 21 Lamp cover Vent (heated air exhaust) Projection lens Quick-release button External control panel (See "Projector" on page for details.) Focus ring Vent (cool air intake) Front IR remote sensor AC power cord inlet 10. -
Page 6: Controls And Functions
TEMPerature warning light Lights up red if the projector's temperature becomes too high. See "Indicators" on page 56 POWER indicator light Lights up or flashes when the projector is under operation. See page 56 for details. Power Toggles the projector on or off. -
Page 7: Remote Control
Remote control Power Toggles the projector on or off. "Starting up the projector" on page 22 "Shutting down the projector" on page 42 FREEZE Freezes the projected image. See "Freezing the image" on page 39 details. Left When the On-Screen Display (OSD) -
Page 8: Remote Control Effective Range
Infra-Red (IR) remote control sensors are located on the front and the back of the projector. The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensors to function correctly. The distance between the remote control and the sensors should not exceed 8 meters (~ 26 feet). -
Page 9: Positioning Your Projector
Your room layout or personal preference will dictate which installation location you select. Take into consideration the size and position of your screen, the location of a suitable power outlet, as well as the location and distance between the projector and the rest of your equipment. -
Page 10: Obtaining A Preferred Projected Image Size
The distance from the projector lens to the screen, the zoom setting, and the video format each factors in the projected image size. 4:3 is the native aspect ratio of this projector. To be able to project a complete 16:9 (widescreen) aspect ratio image, the projector can resize and scale a widescreen image to the projector's native aspect width. -
Page 11: How To Determine The Recommended Screen Size For A Given Distance
InFocus has provided a table of 4:3-aspect-ratio screen sizes to assist you in determining the ideal location for your projector. There are two dimensions to consider, the perpendicular horizontal distance from the center of the screen (projection distance), and the vertical offset height of the projector from the horizontal edge of the screen (offset). - Page 12 Feet Inches There is 3% tolerance among these numbers due to optical component variations. InFocus recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector's optical characteristics.
-
Page 13: Connection
Connecting a computer or monitor Connecting a computer The projector provides a VGA and DVI input sockets that allow you to connect it to both IBM® compatibles and Macintosh® computers. A Mac adapter (an optional accessory) is needed if you are connecting legacy version Macintosh computers. - Page 14 VGA to DVI-A iii. Audio cable Many notebooks do not turn on their external video ports when connected to a projector. Usually a key combo like FN + F3 or CRT/LCD key turns the external display on/off. Locate a function key labeled CRT/LCD or a function key with a monitor symbol on the notebook.
-
Page 15: Connecting A Monitor
If you want to view your presentation close-up on a monitor as well as on the screen, you can connect the D-SUB OUT signal output socket on the projector to an external monitor with a VGA or VGA to DVI-A cable by following the instructions below. -
Page 16: Connecting Video Source Devices
• Video (composite) You need only connect the projector to a Video source device using just one of the above connecting methods, however each provides a different level of video quality. The method you choose will most likely depend upon the availability of... - Page 17 Connecting a DVI source device The projector provides a DVI input socket that allows you to connect it to a DVI source device like a DVD player, or a VGA output device like a notebook or desktop computer. There are three types of DVI connectors: DVI-A, DVI-D, and DVI-I. The DVI-I socket is an integrated connector which supports both formats: DVI-A, and DVI-D.
- Page 18 The final connection path should be like that shown in the following diagram: In the unlikely event that you connect the projector to a DVD player via the projector’s DVI-D input and the projected picture displays wrong colors, please change the color space to YUV.
-
Page 19: Connecting A Component Video Source Device
Component Video to VGA (D-Sub) adaptor cable • The projector is only capable of playing mixed mono audio, even if a stereo audio input is connected. See "Connecting audio" on page 16 • If the selected video image is not displayed after the projector is turned on and the correct video source has been selected, check that the Video source device is turned on and operating correctly. -
Page 20: Connecting An S-Video Source Device
The final connection path should be like that shown in the following diagram: A/V device • The projector is only capable of playing mixed mono audio, even if a stereo audio input is connected. See "Connecting audio" on page 16 •... -
Page 21: Connecting A Composite Video Source Device
The final connection path should be like that shown in the following diagram: A/V device Video cable • The projector is only capable of playing mixed mono audio, even if a stereo audio input is connected. See "Connecting audio" on page 16 •... -
Page 22: Operation
If the projector doesn't detect a valid signal, the 'No Signal' message will continue displaying until an input source signal is found. You can also press SOURCE on the projector or remote control to select your desired input signal. See Operation "Utilizing the password function"... -
Page 23: Using The Menus
Using the menus The projector is equipped with On-Screen Display (OSD) menus for making various adjustments and settings. Below is the overview of the OSD menu. Main menu icon Main menu Highlight Sub-menu Current input signal To use the OSD menus, please set the OSD menu to your familiar language first. -
Page 24: Securing The Projector
The projector has to be installed in a safe place to prevent theft. Otherwise, purchase a lock, such as the Kensington lock, to secure the projector. You can locate a Kensington lock slot on the rear side of the projector. See item 10 on page 5 for details. -
Page 25: Setting A Password
Setting a password Once a password has been set and the power on lock is activated, the projector cannot be used unless the correct password is entered every time the projector is started. Once a password has been set and the splash screen lock is activated, you cannot change the splash screen that displays at projector startup unless the correct password is entered. -
Page 26: Entering The Password Recall Procedure
Keep this reference guide in a safe place. Confirm the new password by re-entering the new password. You have successfully assigned a new password to the projector. Remember to enter the new password next time the projector is started. To leave the OSD menu, press Menu/Exit. -
Page 27: Switching Input Signal
Switching input signal The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. When starting up, the projector automatically searches for the available signals. -
Page 28: Creating Your Own Startup Screen
This function is only available when the DVI-D input socket is in use. Creating your own startup screen In addition to selecting the projector preset startup screen from among InFocus logo, Black or Blue screen, you can make your own startup screen that is a picture projected from your computer or video source. -
Page 29: Adjusting The Projected Image
Adjusting the projected image Adjusting the projection angle The projector is equipped with 1 quick-release adjuster foot and 1 rear adjuster foot. These adjusters change the image height and projection angle. To adjust the projector: Press the quick-release button and lift the front of the projector. -
Page 30: Correcting Keystone
Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen. To correct this, besides adjusting the height of the projector, you will need to manually correct it following ONE of these steps. -
Page 31: Magnifying And Searching For Details On The Projected Picture
Use the directional arrows ( , on the projector or remote control to navigate the picture. To restore the picture to its original size, press AUTO. You can also press Digital Zoom -. -
Page 32: Selecting The Aspect Ratio
The 'aspect ratio' is the ratio of the image width to the image height. Most analog TV and computers are in 4:3 ratio, which is the default for this projector, and digital TV and DVDs are usually in 16:9 ratio. -
Page 33: Optimizing The Image
Brightest mode (Default): Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high brightness is required, such as using the projector in well lit rooms. Presentation mode: Is designed for presentations. The brightness is emphasized in this mode to match PC and notebook coloring. -
Page 34: Using Wall Color
Setting the User 1/User 2 mode There are two user-definable modes if the current available picture modes are not suitable for your need. You can use one of the picture modes (except the User 1/2) as a starting point and customize the settings. Press Menu/Exit to open the On-Screen Display (OSD) menu. -
Page 35: Adjusting Brightness
Adjusting Sharpness Highlight Sharpness in the PICTURE menu and adjust the values by pressing on the projector or remote control. The higher the value, the sharper the picture becomes. The lower the value, the softer the picture becomes. -
Page 36: Selecting A Color Temperature
You will need to use a colorimeter (color light meter), and provide a set of suitable source images to measure color reproduction. These tools are not provided with the projector, however, your projector supplier should be able to provide you with suitable guidance, or even an experienced professional installer. - Page 37 To adjust the settings: Go to the PICTURE menu and highlight 3D Color Management. Press Mode/Enter and the 3D Color Management page displays. Highlight Primary Color and press Yellow, Green, Cyan, Blue, or Magenta. Press to highlight Hue and press range will include colors consisted of more proportions of its two adjacent colors.
-
Page 38: Setting The Presentation Timer
Setting the presentation timer The presentation timer can indicate the presentation time on the screen to help you achieve better time management when giving presentations. Follow these steps to utilize this function: Go to the SYSTEM SETUP: Basic > Presentation Timer menu and press Mode/ Enter to display the Presentation Timer page. -
Page 39: Locking Control Keys
With the control keys on the projector locked, you can prevent your projector settings from being changed accidentally (by children, for example). When the Panel Key Lock is on, no control keys on the projector will operate except Power. Press... -
Page 40: Hiding The Image
Hiding the image In order to draw the audience's full attention to the presenter, you can use BLANK on the projector or remote control to hide the screen image. The word 'BLANK' appears in the corner of the screen while the image is hidden. -
Page 41: Adjusting The Sound
Adjusting the sound The sound adjustments made as below will have an effect on the projector speaker. Be sure you have made a correct connection to the projector audio input. See "Connection" on page 13 Muting the sound To temporarily turn off the sound, Press Menu/Exit and then press menu is highlighted. -
Page 42: Shutting Down The Projector
Disconnect the power cord from the wall socket. If the projector is not properly shut down, to protect the lamp, when you attempt to re-start the projector, the fans will run for a few minutes to cool down. Press Power again to start the projector after the fans stop and the Power indicator light turns orange. -
Page 43: Menu Operation
Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected. Main menu Sub-menu Wall Color Aspect Ratio Keystone DISPLAY Position Phase H. Size Digital Zoom Preset Mode Reference Mode Brightness Contrast Color Tint PICTURE... -
Page 44: System Setup
Security Settings Reset All Settings Note that the menu items are available when the projector detects at least one valid signal. If there is no equipment connected to the projector or no signal detected, limited menu items are accessible. Operation... -
Page 45: Display Menu
DISPLAY menu FUNCTION DESCRIPTION (default setting/ value) Correct the projected picture’s color when the projection surface Wall Color is not white. See (Off) on page 35 There are four options to set the image's aspect ratio depending Aspect Ratio on your input signal source. See (Auto) page 32 Corrects any keystoning of the image. -
Page 46: Picture Menu
Operation DESCRIPTION Pre-defined picture modes are provided so you can optimize your projector image set-up to suit your program type. See "Selecting a picture mode" on page 33 Selects an picture mode that most suits your need for the image quality and further fine-tune the image based on the selections listed on the same page below. - Page 47 Controller (Disable) Allows you to select which logo screen will display during projector Splash start-up. Four options are available: InFocus logo, Black screen, Screen Blue screen or My Screen. (InFocus logo) Captures and stores the projected picture as My Screen. See My Screen "Creating your own startup screen"...
- Page 48 (default setting / value) Enables or disables the Quick Cooling function. Selecting On Quick enables the function and projector cooling time will be shortened Cooling from a normal 90-second duration to approximately 30 seconds. (On) A mode for operation in high altitude areas. See High Altitude high altitude environment"...
-
Page 49: Information Menu
INFORMATION menu This menu shows you the current operating status of the projector. Some picture adjustments are available only when certain input sources are in use. Unavailable adjustments are not shown on the screen. FUNCTION DESCRIPTION Source Shows the current signal source. -
Page 50: Maintenance
Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing. -
Page 51: Lamp Information
"Setting Lamp Mode as Economic" The lamp hour in Economic mode is calculated as 3/4 of that in normal mode. That is, using the projector in Economic mode helps to extend the lamp hour by 1/3. To obtain the lamp hour information: Press Menu/Exit and then press menu is highlighted. -
Page 52: Timing Of Replacing The Lamp
The Lamp indicator light and Temperature warning light will light up if the lamp becomes too hot. Turn the power off and let the projector cool for 45 minutes. If the Lamp or Temp indicator still lights up after turning the power back on, please contact your dealer. See page 56 for details. -
Page 53: Replacing The Lamp
To reduce the risk of electrical shock, always turn the projector off and disconnect the power cord before changing the lamp. • To reduce the risk of severe burns, allow the projector to cool for at least 45 minutes before replacing the lamp. •... - Page 54 • Do not insert your hands into the projector after the lamp is removed. If you touch the optical components inside, it could cause color unevenness and distortion of the projected images.
- Page 55 Do not over tighten the screw. Ensure the handle is fully laid flat and locked in place. Replace the lamp cover on the projector. 10. Use a coin to turn the screw clockwise until the lamp cover is secured. CAUTION •...
- Page 56 Orange Green Green Green Maintenance Status & Description The projector has just been connected to a power outlet or the lamp door is open. Stand-by mode. Powering up. Normal operation. The projector needs 90 seconds to cool down as it was abnormally shut down without the normal cooling down process.
-
Page 57: Troubleshooting
You do not remember the password. Remedy Plug the power cord into the AC inlet on the projector, and plug the power cord into the power outlet. If the power outlet has a switch, make sure that it is switched on. -
Page 58: Specifications
Specifications Projector specifications All specifications are subject to change without notice. Optical Resolution 1024 x 768 XGA Display system 1-CHIP DMD Lens F/Number F=2.42 (fixed) Lamp 200 W lamp Electrical Power supply AC100–240V, 3.2A, 50-60 Hz (Automatic) Power consumption 365 W (Max); 5 W (Standby) -
Page 59: Dimensions
Dimensions 274.87 mm (W) x 131.30 mm (H) x 304.99 mm (D) Timing chart Supported timing for PC (including DVI-D) input Horizontal Resolution Frequency (kHz) 31.469 37.861 640 x 480 37.500 43.269 720 x 400 31.469 37.879 48.077 800 x 600 46.875 53.674 48.363... - Page 60 Supported timing for Component-YP Signal Format 480i(525i)@60Hz 480p(525p)@60Hz 576i(625i)@50Hz 576p(625p)@50Hz 720p(750p)@60Hz 720p(750p)@50Hz 1080i(1125i)@60Hz 1080i(1125i)@50Hz Supported timing for Video and S-Video inputs Video mode NTSC SECAM PAL-M PAL-N PAL-60 NTSC4.43 Specifications Horizontal Frequency (kHz) 15.73 31.47 15.63 31.25 45.00 37.50 33.75 28.13 Horizontal Vertical...
-
Page 61: Copyright Information
Copyright information Copyright Copyright 2008 by InFocus Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of InFocus Corporation.
