Projector exterior view
Front/upper side
1
2
3
4
Rear/lower side
14 15
13
9
10
11
12
4
P U
S H
16
17
18
19 20 21
1.
Lamp cover
2.
Vent (heated air exhaust)
5
3.
Projection lens
4.
Quick-release button
5.
External control panel
(See
6
for details.)
6
6.
Focus ring
7.
Vent (cool air intake)
7
8.
Front IR remote sensor
9.
AC power cord inlet
8
10. Kensington anti-theft lock
slot
11. Rear adjuster foot
12. Ceiling mounting holes
13. Rear IR remote sensor
14. Video input socket
15. S-Video input socket
22
16. RGB signal output socket
17. RGB (PC)/Component
video (YPbPr/ YCbCr)
signal input socket
18. DVI input socket
19. Audio socket
20. 12VDC output terminal
21. USB socket
22. RS-232 control port
23. Speaker grill
23
