InFocus Learn Big XS1 Reference Manual page 12

4:3 Screen Diagonal
4:3 screen diagonal
Feet Inches
6
7
8
9
There is 3% tolerance among these numbers due to optical component variations. InFocus
recommends that if you intend to permanently install the projector, you should physically test
the projection size and distance using the actual projector in situ before you permanently
install it, so as to make allowance for this projector's optical characteristics. This will help you
determine the exact mounting position so that it best suits your installation location.
12 Positioning your projector
Offset
Recommended projection distance
mm
1692
72 1829
2000
84 2134
96 2438
2500
108 2743
3000
3007
Screen
Center of lens
Projection distance
from screen in mm
900
973
1064
1135
1297
1330
1459
1596
1600
Vertical offset in
mm
101
110
120
128
146
150
165
180
180
