Summary of Contents for HULALA HOME DKHE0990
- Page 1 HULALA ITEM NO.DKHE0990 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/20...
- Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
-
Page 3: Explosive View
EXPLOSIVE VIEW 2PERSONEN 03/20... -
Page 4: Parts List
PARTS LIST 04/20... - Page 5 PARTS LIST 05/20...
-
Page 6: Hardware List
HARDWARE LIST Φ1/4''*35mm 1/4"*16mm Ø8x30mm Φ15*10mm 1/4"*12mm 1/4"*32mm 1/4"*10mm 5/16"*19mm 110*4mm 1/4"*50mm 32*20*18*2mm 5/16"*45mm 5/32"*1-1/4"mm 4*32mm TOOL LIST not include 06/20... - Page 7 HARDWARE SPARE LIST Φ1/4''*35mm Ø8x30mm 1/4"*16mm Φ15*10mm 1/4"*12mm 1/4"*32mm 1/4"*10mm 32*20*18*2mm 5/16"*19mm 5/16"*45mm 3.5*32mm 1/4"*50mm 5/32"*1 "mm 07/20...
- Page 8 ASSEMBLY INSTRUCTIONS STEP-1 1.Align the holes in part( A,C,D,E,F), tighten with screwdriver tighten #1。 Φ1/4''*35mm 08/20...
- Page 9 ASSEMBLY INSTRUCTIONS STEP-2 insert wooden dowel #2 by hand. 1.Prepare for part D, 1.Connect the part G with part D. align the hole in the part F,insert the bolt #1 and wooden dowel #2 in part D into part G. insert cam bolt #3 into the corresponding hole of panel G,and tighten the nuts #3 with a screwdriver Ø8x30mm Φ15*10mm...
- Page 10 ASSEMBLY INSTRUCTIONS STEP-3 insert wooden dowel #2 by hand 1.Prepare for part E, .Connect the part C with part E. align the hole in the part C,insert the bolt #1 and wooden dowel #2 in part E into part C. insert cam bolt #3 into the corresponding hole of panel C,and tighten the nuts #3 with a screwdriver Ø8x30mm Φ15*10mm...
- Page 11 ASSEMBLY INSTRUCTIONS STEP-4 insert wooden dowel #2 by hand 1.Prepare for part (G&D&C&E), .Connect the part (C&E) with part (D&G). align the hole in the part (C&E),insert the bolt #1 and wooden dowel #2 in part (D&G) into part(C&E). insert cam bolt #3 into the corresponding hole of panel (E&G),and tighten the nuts #3 with a screwdriver Φ15*10mm Ø8x30mm...
- Page 12 ASSEMBLY INSTRUCTIONS insert wooden dowel #2 by hand 1.Prepare for part (A), .Insert screw #4 into washer #5,Install part #9 on panel A using screw #4 and washer #5.Connect the part (C&D&E) with part A. align the hole in the part (C&E&D),insert the bolt #1 and wooden dowel #2 in part A into part(C&E&D).
- Page 13 ASSEMBLY INSTRUCTIONS STEP-6 1.Prepare for part (Q),insert wooden dowel #2 by hand. Use screw #6 to connect bottom plate #F and leg #Q.And use wrench #12 to tighten screw #6. Ø8x30mm 1/4"*16mm 1/4"*32mm 110*4mm 13/20...
- Page 14 ASSEMBLY INSTRUCTIONS STEP-7 Insert the wooden dowel #2 into the part C&D&E as the picture show.Connect the part F the pre-assembled unit in step 6.Place part #7 into the holes of C and D, Insert screw #8 into washer #5.Then align the holes in part B,Insert screw #8 and push it down so that it connects to parts C&D&E.
- Page 15 ASSEMBLY INSTRUCTIONS STEP-8 Insert screw #11 into washer #10 and use screw 11 and washer #10 to attach the feet to part A.next,and tighten the screw #11 with an Allen key #12 . 5/16"*45mm 110*4mm 5/16"*19mm 15/20...
- Page 16 ASSEMBLY INSTRUCTIONS STEP-9 1.Connect part (J&L) to part I using screw #13 and tighten it with screwdriver .Slide in the part (K) into the groove in part (J&L). make sure they are also in groove in part (I). 1.Connect part (P&N) to part H using screw #13 and tighten it with screwdriver . 2.Use screw# 14 to attach handle #15 to the corresponding hole of panel(H), tighten screw with screwdriver .
- Page 17 ASSEMBLY INSTRUCTIONS STEP-10 1.Connect part (P&N) to part O using screw #13 and tighten it with screwdriver .Slide in the part (K) into the groove in part (N&P). make sure they are also in groove in part (O). 1.Connect part (P&N) to part M using screw #13 and tighten it with screwdriver. 2.Use screw# 14 to attach handle #15 to the corresponding hole of panel(M), tighten screw with screwdriver.
- Page 18 ASSEMBLY INSTRUCTIONS STEP-11 Place the drawer into the cabinet. OPEN LOCK 18/20...
- Page 19 ASSEMBLY INSTRUCTIONS STEP-12 The cabinet panel can be lifted up and down. 19/20...
- Page 20 ASSEMBLY INSTRUCTIONS STEP-13 Attention: Before the next step, adjust the feet of the locker to keep it level. 20/20...
