UT-102
VOICE SYNTHESIZER UNIT
The UT-102 announces the accessed frequency in a
clear, electronically generated voice, in English (or
Japanese) when pushing [SPCH] or when a signal is
detected during scan (see p. 31, 32 for settings).
Remove the top cover as shown opposite.
Remove the protected paper attached to the bot-
tom of the UT-102 to expose the adhesive strip.
Connect the UT-102 as shown in the diagram at
right.
Replace the top cover.
FL-52A
CW NARROW FILTER
The IC-R8500 has a CW narrow mode which pro-
vides better S/N (signal-to-noise) and also rejects
nearby interference. The CW narrow filter is helpful
when receiving CW and radio-teletype signals.
Remove the top cover as shown opposite.
Connect the FL-52A as shown in the diagram at
right.
• Make sure it is connected in the proper orientation.
• Attached nuts on the FL-52A are not necessary. If you
want to install the filter more securely, open the MAIN
unit, then use the nuts on the bottom of the MAIN unit.
Replace the top cover.

OPTIONAL INSTALLATIONS

Under the top cover
Under the top cover
12
UT-102
J12
FL-52A
