INSTRUCTION MANUAL
IM443-U v0.7
EMM-D4h
ELECTRICAL MULTIFUNCTION METER
GENERALITY
These digital multimeters allow to monitor all the electrical parameters
present on a distribution line. The local display of 30 electrical parameters
is carried out by 4 display with red LED guaranteeing a good and
contemporary reading of more measures. A simple front panel completes
the intuitive selection of several electrical parameters, with a great quantity
of information. These instruments, over of the instantaneous measures,
display the maximum peak of the main parameters (maximum peak and
maximum demand). The presence of the serial port communication
EIA485 (option) allows the connection in network of more instruments to
realize centralized measure networks.
These multimeters replace in a unique device, all the functions of
voltmeters, ammeters,
varmeters, frequency meters permitting a great economic saving, a reduction of dimension and the wiring energy and
a simplification in the purchase and management of the instruments because this is a model usable at all of need of
local measure in the electrical panel, machine, etc.
AVAILABLE MODELS
It's available four models for DIN rail mounting.
- EMM-D4h basic version in execution for DIN rail mounting 35 mm
- EMM-D4hp as previous version with digital output
- EMM-D4hp-485 as previous version with serial output (RS485)
- EMM-D4hp-485-A as previous version with analog output
OPTIONS
- Power Supply: 20÷60 Vac/dc (-C1)
- Power Supply: 90÷250 Vac/dc (-C2)
- Current Input: 1A (-1A)
- Insulated current inputs (-t)
- Neutral current input (-n)
- Digital input (-DI) (it's not available for version with analog output: EMM-D4hp-485-A)
MEASURED PARAMETERS
parameters
phase and three phase voltages
phase to phase and three phase system voltages
phase and three phase currents
neutral current
phase and three phase power factors
phase and three phase active powers
phase and three phase system reactive powers
phase and three-phase system apparent powers
frequency
temperature
three phase system active energy
three phase system reactive energy
three phase system apparent energy
hour counter
average and peak values (maximums):
maximum phase voltages
maximum phase currents
maximum neutral current
maximum three-phase powers
maximum average phase currents (maximum demand)
maximum average neutral current (maximum demand)
maximum average three-phase powers (maximum demand)
average phase currents
average neutral current
average three-phase powers
EMM-D4h
energy meters, cosphimeters,
instruction manual
wattmeters,
unit of measurement
[V-kV] V
[V-kV] V
[A-kA] A
[A-kA] A
n
PF
[W-kW-MW] W
[VAr-kVAr-MVAr] VAr
[VA-kVA-MVA] VA
[Hz] Hz
[°C] T
 kWh
[kWh]
 kVArh
[kVArh]
 kVAh
[kVAh]
[hr] h
[V-kV] V
[A-kA] A
[A-kA] A
n max
 W
[W-VAr-VA (k-M)]
[A-kA] I
L1 max (avg)
[A-kA] A
n max (avg)
 W
[W-VAr-VA (k-M)]
[A-kA] A
[A-kA] A
n avg
 W
[W-VAr-VA (k-M)]
IM443-U v0.7
initial identification
V V
L1-N L2-N L3-N
V V
L1-L2 L2-L3 L3-L1
A A
L1 L2 L3
PF PF
L1 L2 L3
W W
L1 L2 L3
VAr VAr
L1 L2 L3
VA VA
L1 L2 L3
L1
V
L1-N max L2-N max
A
L1 max L2 max
 VAr
max max
I
L2 max (avg)
 VAr
max (avg) max (avg)
A
L1 avg L2 avg
 VAr
avg avg
pag. 1
 V
L-N
 V
L-L
 A

PF
W
VAr
VA
V
L3-N max
A
L3 max
 VA
max
I
L3 max (avg)
 VA
max (avg)
A
L3 avg
 VA
avg
